1984 Kawasaki ZN 700 LTD Shaft Specs

motorcycle specs

These are the known mechanical and performance specifications for your 1984 Kawasaki ZN 700 LTD Shaft.

Basic Specs

Year1984
MakeKawasaki
ModelKawasaki ZN 700 LTD Shaft
Cost

Engine

Displacement694.00 ccm (42.35 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM10000
Compression9.7:1
Bore/Stroke64.0 x 54.0 mm (2.5 x 2.1 inches)
Valves/Cylinder2
FuelingCarburettor. Keihin CV34 x 4
IgnitionCDI
ExhaustDual stainless megaphone pipes
Lubricationwet sump
CoolingAir

Drivetrain

Gearbox5-speed
Final DriveShaft drive (cardan)
Clutchwet plate
Driveline

Performance

Horespower74.00 HP (54.0 kW)
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity13.90 litres (3.67 gallons)
Emissions

Chassis

Frame Typetubular, double cradle
Rake29.8°
Trail112 mm (4.4 inches)
Front SuspensionTelescopic fork
Front Travel160 mm (6.3 inches)
Rear SuspensionSwing arm with Dual air adjustable shocks
Rear Travel100 mm (3.9 inches)
Seat
Seat Height755 mm (29.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,210 mm (47.6 inches)
Total Length2,220 mm (87.4 inches)
Total Width820 mm (32.3 inches)
Ground Clearance150 mm (5.9 inches)
Wheelbase1,510 mm (59.4 inches)
Dry Weight217.0 kg (478.4 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre110/90-18 61H
Rear Tire/Tyre130/90-16 67H
Front BrakesDouble disc. single piston calipers
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Kawasaki ZN 700 LTD Shaft. This Classic model is powered by a In-line four, four-stroke engine with 694.00 ccm (42.35 cubic inches) of actual displacement before 9.7:1 compression. Fueling is metered via Carburettor. Keihin CV34 x 4 allowing this machine to produce its 74.00 HP (54.0 kW) horsepower and torque. According to our records engine heat of the Kawasaki ZN 700 LTD Shaft is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 110/90-18 61H and the rear is 130/90-16 67H . The entire package is supported by the frame, tubular, double cradle. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. single piston calipers front brakes and Single disc rear brakes. The Kawasaki ZN 700 LTD Shaft was launched in 1984, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
