1998 Kawasaki Voyager XII Specs

motorcycle specs

These are the known mechanical and performance specifications for your 1998 Kawasaki Voyager XII.

Basic Specs

Year1998
MakeKawasaki
ModelKawasaki Voyager XII
Cost

Engine

Displacement1196.00 ccm (72.98 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke78.0 x 62.0 mm (3.1 x 2.4 inches)
Valves/Cylinder4
FuelingCarburettor. Kehin ckv 30 (4) constant Velocity, Diaphram type
Ignition12 v Battery and coil, Transistorized Breakerless
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveShaft drive (cardan)
ClutchWet, Multi-disc, Manual
Driveline

Performance

Horespower97.00 HP (70.8 kW)
Torque11.00 Nm (1.1 kgf-m or 8.1 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption5.22 litres/100 km (19.2 km/l or 45.06 mpg)
Fuel Capacity23.20 litres (6.13 gallons)
Emissions121.1 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake
Trail
Front SuspensionAir/Oil
Front Travel
Rear SuspensionAir/Spring
Rear Travel
Seat
Seat Height755 mm (29.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance140 mm (5.5 inches)
Wheelbase1,620 mm (63.8 inches)
Dry Weight330.0 kg (727.5 pounds)
Wet Weight361.0 kg (795.9 pounds)

Wheels & Brakes

Front Tire/Tyre130/90-16
Rear Tire/Tyre150/90-15
Front BrakesDouble disc. Hydraulic
Front Brake Diameter246 mm (9.7 inches)
Rear BrakesSingle disc. Hydraulic
Rear Brake Diameter256 mm (10.1 inches)
Wheels

Comments

It appears you're interested in specifications for the Kawasaki Voyager XII. This Touring model is powered by a In-line four, four-stroke engine with 1196.00 ccm (72.98 cubic inches) of actual displacement before 10.0:1 compression. Fueling is metered via Carburettor. Kehin ckv 30 (4) constant Velocity, Diaphram type allowing this machine to produce its 97.00 HP (70.8 kW) horsepower and 11.00 Nm (1.1 kgf-m or 8.1 ft.lbs) torque. According to our records engine heat of the Kawasaki Voyager XII is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 130/90-16 and the rear is 150/90-15 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Hydraulic front brakes and Single disc. Hydraulic rear brakes. The Kawasaki Voyager XII was launched in 1998, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
