2001 Highland 950 V2 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2001 Highland 950 V2.

Basic Specs

Year2001
MakeHighland
ModelHighland 950 V2
Cost

Engine

Displacement950.00 ccm (57.97 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression
Bore/Stroke95.0 x 66.0 mm (3.7 x 2.6 inches)
Valves/Cylinder4
FuelingCarburettor
Ignition
Exhaust
Lubrication
Cooling

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower76.00 HP (55.5 kW)
Torque
Top Speed180.0 km/h (111.8 mph)

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity22.00 litres (5.81 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front Suspension
Front Travel280 mm (11.0 inches)
Rear Suspension
Rear Travel300 mm (11.8 inches)
Seat
Seat Height910 mm (35.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance
Wheelbase1,530 mm (60.2 inches)
Dry Weight145.0 kg (319.7 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre90/90-21
Rear Tire/Tyre140/80-18
Front BrakesSingle disc
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Highland 950 V2. This Enduro / offroad model is powered by a V2, four-stroke engine with 950.00 ccm (57.97 cubic inches) of actual displacement before compression. Fueling is metered via Carburettor allowing this machine to produce its 76.00 HP (55.5 kW) horsepower and torque. According to our records engine heat of the Highland 950 V2 is moderated by . You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 90/90-21 and the rear is 140/80-18 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The Highland 950 V2 was launched in 2001, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
