2003 Ducati Monster 620 S i.e. Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2003 Ducati Monster 620 S i.e..

Basic Specs

Year2003
MakeDucati
ModelDucati Monster 620 S i.e.
Cost

Engine

Displacement618.00 ccm (37.71 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression10.5:1
Bore/Stroke80.0 x 61.5 mm (3.1 x 2.4 inches)
Valves/Cylinder2
FuelingInjection
Ignition
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox5-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower60.00 HP (43.8 kW)
Torque53.30 Nm (5.4 kgf-m or 39.3 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity15.00 litres (3.96 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front Suspension
Front Travel130 mm (5.1 inches)
Rear Suspension
Rear Travel148 mm (5.8 inches)
Seat
Seat Height795 mm (31.3 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height795 mm (31.3 inches)
Total Length2,100 mm (82.7 inches)
Total Width
Ground Clearance
Wheelbase1,440 mm (56.7 inches)
Dry Weight177.0 kg (390.2 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/60-ZR17
Rear Tire/Tyre160/60-ZR17
Front BrakesDouble disc
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc
Rear Brake Diameter245 mm (9.6 inches)
Wheels

Comments

It appears you're interested in specifications for the Ducati Monster 620 S i.e.. This Naked bike model is powered by a V2, four-stroke engine with 618.00 ccm (37.71 cubic inches) of actual displacement before 10.5:1 compression. Fueling is metered via Injection allowing this machine to produce its 60.00 HP (43.8 kW) horsepower and 53.30 Nm (5.4 kgf-m or 39.3 ft.lbs) torque. According to our records engine heat of the Ducati Monster 620 S i.e. is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/60-ZR17 and the rear is 160/60-ZR17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Ducati Monster 620 S i.e. was launched in 2003, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
