2004 Kawasaki Ninja ZX-10R (ZX1000-C1) Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2004 Kawasaki Ninja ZX-10R (ZX1000-C1).

Basic Specs

Year2004
MakeKawasaki
ModelKawasaki Ninja ZX-10R (ZX1000-C1)
TypeSport
Cost

Engine

Displacement998.00 ccm (60.90 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression
Bore/Stroke76.0 x 55.0 mm (3.0 x 2.2 inches)
Valves/Cylinder4
FuelingInjection
Ignition
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower175.00 HP (127.7 kW)
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity
Emissions

Chassis

Frame TypeBackbone/Twin-tube, aluminium (Pressed/die-cast composite structure)
Rake24.0°
Trail102 mm (4.0 inches)
Front Suspension43 mm inverted fork with top-out springs
Front Travel
Rear SuspensionBottom-Link Uni-Trak with gas-charged shock and top-out spring
Rear Travel
Seat
Seat Height820 mm (32.3 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height708 mm (27.9 inches)
Total Length2,045 mm (80.5 inches)
Total Width1,385 mm (54.5 inches)
Ground Clearance
Wheelbase1,385 mm (54.5 inches)
Dry Weight170.0 kg (374.8 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-ZR17 M/C
Rear Tire/Tyre190/50-ZR17 M/C
Front BrakesDouble disc
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Kawasaki Ninja ZX-10R (ZX1000-C1). This Sport model is powered by a In-line four, four-stroke engine with 998.00 ccm (60.90 cubic inches) of actual displacement before compression. Fueling is metered via Injection allowing this machine to produce its 175.00 HP (127.7 kW) horsepower and torque. According to our records engine heat of the Kawasaki Ninja ZX-10R (ZX1000-C1) is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-ZR17 M/C and the rear is 190/50-ZR17 M/C . The entire package is supported by the frame, Backbone/Twin-tube, aluminium (Pressed/die-cast composite structure). We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Kawasaki Ninja ZX-10R (ZX1000-C1) was launched in 2004, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
