2005 BMW F 650 CS Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2005 BMW F 650 CS.

Basic Specs

Year2005
MakeBMW
ModelBMW F 650 CS
Cost

Engine

Displacement652.00 ccm (39.79 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression11.5:1
Bore/Stroke100.0 x 83.0 mm (3.9 x 3.3 inches)
Valves/Cylinder4
FuelingInjection. Electronic intake pipe injection / BMW engine management, dual ignition
Ignition
Exhaust
LubricationDry sump
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveBelt
ClutchMultiple-disc clutch in oil-bath, mechanically operated
Driveline

Performance

Horespower49.61 HP (36.2 kW)
Torque62.00 Nm (6.3 kgf-m or 45.7 ft.lbs)
Top Speed178.0 km/h (110.6 mph)

Fuel Economy & Polution

Fuel Consumption3.00 litres/100 km (33.3 km/l or 78.41 mpg)
Fuel Capacity15.00 litres (3.96 gallons)
Emissions69.6 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeBridging frame, steel section, with integrated oil tank and bolted-on rear frame
Rake27.9°
Trail86 mm (3.4 inches)
Front SuspensionTelescopic fork, stanchion diameter 41 mm
Front Travel35 mm (1.4 inches)
Rear SuspensionDie-cast aluminium single-sided swinging arm with rear wheel axle and eccentric adjustment, central spring strut action via lever system
Rear Travel135 mm (5.3 inches)
Seat
Seat Height780 mm (30.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,158 mm (45.6 inches)
Total Length2,142 mm (84.3 inches)
Total Width915 mm (36.0 inches)
Ground Clearance
Wheelbase1,493 mm (58.8 inches)
Dry Weight169.6 kg (373.9 pounds)
Wet Weight187.0 kg (412.3 pounds)

Wheels & Brakes

Front Tire/Tyre110/70-ZR17
Rear Tire/Tyre170/60-ZR17
Front BrakesDouble disc
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc
Rear Brake Diameter240 mm (9.4 inches)
Wheels

Comments

It appears you're interested in specifications for the BMW F 650 CS. This Naked bike model is powered by a Single cylinder, four-stroke engine with 652.00 ccm (39.79 cubic inches) of actual displacement before 11.5:1 compression. Fueling is metered via Injection. Electronic intake pipe injection / BMW engine management, dual ignition allowing this machine to produce its 49.61 HP (36.2 kW) horsepower and 62.00 Nm (6.3 kgf-m or 45.7 ft.lbs) torque. According to our records engine heat of the BMW F 650 CS is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 110/70-ZR17 and the rear is 170/60-ZR17 . The entire package is supported by the frame, Bridging frame, steel section, with integrated oil tank and bolted-on rear frame. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The BMW F 650 CS was launched in 2005, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

ABS brakes.
