2005 Kawasaki Vulcan 1600 Nomad Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2005 Kawasaki Vulcan 1600 Nomad.

Basic Specs

Year2005
MakeKawasaki
ModelKawasaki Vulcan 1600 Nomad
CostUS$ 12999. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1550.00 ccm (94.58 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression9.0:1
Bore/Stroke102.0 x 95.0 mm (4.0 x 3.7 inches)
Valves/Cylinder4
FuelingInjection. Digital fuel injection with (2) 36mm throttle bodies
IgnitionDigital
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveShaft drive (cardan)
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity20.06 litres (5.30 gallons)
Emissions

Chassis

Frame TypeHigh-tensile steel, double cradle
Rake32.0°
Trail
Front Suspension43mm hydraulic fork
Front Travel
Rear SuspensionDual hydraulic shocks
Rear Travel
Seat
Seat Height706 mm (27.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance135 mm (5.3 inches)
Wheelbase1,684 mm (66.3 inches)
Dry Weight
Wet Weight

Wheels & Brakes

Front Tire/Tyre150/80-16
Rear Tire/Tyre170/70-16
Front BrakesDouble disc
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc
Rear Brake Diameter300 mm (11.8 inches)
Wheels

Comments

It appears you're interested in specifications for the Kawasaki Vulcan 1600 Nomad. This Custom / cruiser model is powered by a V2, four-stroke engine with 1550.00 ccm (94.58 cubic inches) of actual displacement before 9.0:1 compression. Fueling is metered via Injection. Digital fuel injection with (2) 36mm throttle bodies allowing this machine to produce its horsepower and torque. According to our records engine heat of the Kawasaki Vulcan 1600 Nomad is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 150/80-16 and the rear is 170/70-16 . The entire package is supported by the frame, High-tensile steel, double cradle. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Kawasaki Vulcan 1600 Nomad was launched in 2005, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
