These are the known mechanical and performance specifications for your 2005 Yamaha XT 225.

Basic Specs

Year2005
MakeYamaha
ModelYamaha XT 225
CostUS$ 4099. Prices depend on country, taxes, accessories, etc.

Engine

Displacement223.00 ccm (13.61 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.5:1
Bore/Stroke70.0 x 58.0 mm (2.8 x 2.3 inches)
Valves/Cylinder
FuelingCarburettor
Ignition
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity8.70 litres (2.30 gallons)
Emissions

Chassis

Frame Type
Rake24.0°
Trail
Front SuspensionTelescopic fork
Front Travel226 mm (8.9 inches)
Rear SuspensionSwingarm w/rebound-adjustable single shock
Rear Travel191 mm (7.5 inches)
Seat
Seat Height810 mm (31.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,161 mm (45.7 inches)
Total Length2,070 mm (81.5 inches)
Total Width805 mm (31.7 inches)
Ground Clearance284 mm (11.2 inches)
Wheelbase1,349 mm (53.1 inches)
Dry Weight
Wet Weight

Wheels & Brakes

Front Tire/Tyre2.75-21
Rear Tire/Tyre120/80-18
Front BrakesSingle disc
Front Brake Diameter220 mm (8.7 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter110 mm (4.3 inches)
Wheels

Comments

It appears you're interested in specifications for the Yamaha XT 225. This Allround model is powered by a Single cylinder, four-stroke engine with 223.00 ccm (13.61 cubic inches) of actual displacement before 9.5:1 compression. Fueling is metered via Carburettor allowing this machine to produce its horsepower and torque. According to our records engine heat of the Yamaha XT 225 is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 2.75-21 and the rear is 120/80-18 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Expanding brake (drum brake) rear brakes. The Yamaha XT 225 was launched in 2005, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
