2006 Harley-Davidson FLSTN Softail Deluxe Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2006 Harley-Davidson FLSTN Softail Deluxe.

Basic Specs

Year2006
MakeHarley-Davidson
ModelHarley-Davidson FLSTN Softail Deluxe
CostUS$ 16995. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1442.15 ccm (88.00 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression8.9:1
Bore/Stroke95.3 x 101.6 mm (3.8 x 4.0 inches)
Valves/Cylinder2
FuelingCarburettor
Ignition
ExhaustChrome, over/under shotgun with shorty duals
Lubrication
CoolingAir

Drivetrain

Gearbox5-speed
Final DriveBelt
ClutchMulti-plate clutch with diaphragm spring in oil bath
Driveline

Performance

Horespower
Torque115.26 Nm (11.8 kgf-m or 85.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption5.00 litres/100 km (20.0 km/l or 47.04 mpg)
Fuel Capacity18.92 litres (5.00 gallons)
Emissions116.0 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake32.0°
Trail
Front Suspension
Front Travel
Rear Suspension
Rear Travel
Seat
Seat Height622 mm (24.5 inches) If adjustable, lowest setting.
Alt. Seat Height673 mm (26.5 inches) If adjustable, highest setting.
Total Height
Total Length2,405 mm (94.7 inches)
Total Width
Ground Clearance122 mm (4.8 inches)
Wheelbase1,638 mm (64.5 inches)
Dry Weight314.3 kg (693.0 pounds)
Wet Weight328.4 kg (724.0 pounds)

Wheels & Brakes

Front Tire/TyreMT90-B16
Rear Tire/TyreMU85-B16
Front BrakesSingle disc
Front Brake Diameter292 mm (11.5 inches)
Rear BrakesSingle disc
Rear Brake Diameter292 mm (11.5 inches)
Wheels

Comments

It appears you're interested in specifications for the Harley-Davidson FLSTN Softail Deluxe. This Custom / cruiser model is powered by a V2, four-stroke engine with 1442.15 ccm (88.00 cubic inches) of actual displacement before 8.9:1 compression. Fueling is metered via Carburettor allowing this machine to produce its horsepower and 115.26 Nm (11.8 kgf-m or 85.0 ft.lbs) torque. According to our records engine heat of the Harley-Davidson FLSTN Softail Deluxe is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is MT90-B16 and the rear is MU85-B16 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The Harley-Davidson FLSTN Softail Deluxe was launched in 2006, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Low 24.5 in. seat height. Integrated luggage rack. Pullback risers and handlebar. Quick change one-up or two-up seating. Wire laced wheels with wide whitewall tires.
