These are the known mechanical and performance specifications for your 2006 Yamaha Stratoliner.
Basic Specs
Year2006
MakeYamaha
ModelYamaha Stratoliner
TypeTouring
CostUS$ 15180. Prices depend on country, taxes, accessories, etc.
Engine
Displacement1851.85 ccm (113.00 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression9.5:1
Bore/Stroke100.0 x 118.0 mm (3.9 x 4.6 inches)
Valves/Cylinder
FuelingInjection. Twin-bore electronic fuel injection, w/ 43mm throttle bodies and throttle position sensor
IgnitionDigital TCI
Exhaust
Lubrication
CoolingAir
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity17.03 litres (4.50 gallons)
Emissions
Chassis
Frame TypeAluminium
Rake
Trail
Front Suspension46mm telescopic fork
Front Travel135 mm (5.3 inches)
Rear SuspensionSingle shock, link-type
Rear Travel109 mm (4.3 inches)
Seat
Seat Height734 mm (28.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,581 mm (101.6 inches)
Total Width935 mm (36.8 inches)
Ground Clearance155 mm (6.1 inches)
Wheelbase1,715 mm (67.5 inches)
Dry Weight343.8 kg (758.0 pounds)
Wet Weight
Wheels & Brakes
Front Tire/Tyre130/70-18
Rear Tire/Tyre190/60-17
Front BrakesDouble disc
Front Brake Diameter298 mm (11.7 inches)
Rear BrakesSingle disc
Rear Brake Diameter320 mm (12.6 inches)
Wheels
Comments
