2006 Yamaha Stratoliner Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2006 Yamaha Stratoliner.

Basic Specs

Year2006
MakeYamaha
ModelYamaha Stratoliner
CostUS$ 15180. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1851.85 ccm (113.00 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression9.5:1
Bore/Stroke100.0 x 118.0 mm (3.9 x 4.6 inches)
Valves/Cylinder
FuelingInjection. Twin-bore electronic fuel injection, w/ 43mm throttle bodies and throttle position sensor
IgnitionDigital TCI
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox5-speed
Final DriveBelt
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity17.03 litres (4.50 gallons)
Emissions

Chassis

Frame TypeAluminium
Rake
Trail
Front Suspension46mm telescopic fork
Front Travel135 mm (5.3 inches)
Rear SuspensionSingle shock, link-type
Rear Travel109 mm (4.3 inches)
Seat
Seat Height734 mm (28.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,581 mm (101.6 inches)
Total Width935 mm (36.8 inches)
Ground Clearance155 mm (6.1 inches)
Wheelbase1,715 mm (67.5 inches)
Dry Weight343.8 kg (758.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre130/70-18
Rear Tire/Tyre190/60-17
Front BrakesDouble disc
Front Brake Diameter298 mm (11.7 inches)
Rear BrakesSingle disc
Rear Brake Diameter320 mm (12.6 inches)
Wheels

Comments

It appears you're interested in specifications for the Yamaha Stratoliner. This Touring model is powered by a V2, four-stroke engine with 1851.85 ccm (113.00 cubic inches) of actual displacement before 9.5:1 compression. Fueling is metered via Injection. Twin-bore electronic fuel injection, w/ 43mm throttle bodies and throttle position sensor allowing this machine to produce its horsepower and torque. According to our records engine heat of the Yamaha Stratoliner is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 130/70-18 and the rear is 190/60-17 . The entire package is supported by the frame, Aluminium. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Yamaha Stratoliner was launched in 2006, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
