2008 Bimota DB5S Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2008 Bimota DB5S.

Basic Specs

Year2008
MakeBimota
ModelBimota DB5S
TypeSport
Cost

Engine

Displacement1079.00 ccm (65.84 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression10.5:1
Bore/Stroke98.0 x 71.5 mm (3.9 x 2.8 inches)
Valves/Cylinder2
FuelingInjection. Electronic fule injection-45mm throttle body
Ignition
Exhaust
LubricationWet sump
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchOil bath multi-plate with hydraulic control
Driveline

Performance

Horespower95.00 HP (69.3 kW)
Torque102.97 Nm (10.5 kgf-m or 76.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity16.00 litres (4.23 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionUD Marzocchi TiN Coated Fork Full Adjustable (Pre-load, Compression, Rebound)
Front Travel
Rear SuspensionMonoshock Extreme Tech Full Adjustable (Pre-load -External Hydraulic Device, Compression, Rebound
Rear Travel
Seat
Seat Height800 mm (31.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,230 mm (48.4 inches)
Total Length2,045 mm (80.5 inches)
Total Width750 mm (29.5 inches)
Ground Clearance170 mm (6.7 inches)
Wheelbase1,440 mm (56.7 inches)
Dry Weight185.0 kg (407.9 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-17
Rear Tire/Tyre180/55-17
Front BrakesDouble disc. Double Ø320 mm Floating Discs Brembo, Radial Caliper Brembo 4-Pistons, 4-Pads
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. Ø230 mm Disc Brembo, 2-Pistons, 2-Pads Brembo
Rear Brake Diameter230 mm (9.1 inches)
Wheels

Comments

It appears you're interested in specifications for the Bimota DB5S. This Sport model is powered by a V2, four-stroke engine with 1079.00 ccm (65.84 cubic inches) of actual displacement before 10.5:1 compression. Fueling is metered via Injection. Electronic fule injection-45mm throttle body allowing this machine to produce its 95.00 HP (69.3 kW) horsepower and 102.97 Nm (10.5 kgf-m or 76.0 ft.lbs) torque. According to our records engine heat of the Bimota DB5S is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-17 and the rear is 180/55-17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Double Ø320 mm Floating Discs Brembo, Radial Caliper Brembo 4-Pistons, 4-Pads front brakes and Single disc. Ø230 mm Disc Brembo, 2-Pistons, 2-Pads Brembo rear brakes. The Bimota DB5S was launched in 2008, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
