2008 Buell 1125R Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2008 Buell 1125R.

Basic Specs

Year2008
MakeBuell
ModelBuell 1125R
TypeSport
Cost

Engine

Displacement1125.86 ccm (68.70 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression12.3:1
Bore/Stroke
Valves/Cylinder4
FuelingInjection. Dual 61 mm down draft throttle bodies, DDFI III fuel injection
Ignition
ExhaustTuned, tri-pass resonance chamber with integral helmholtz tuning and mass-centralized mounting
LubricationDry-sump with integrated oil reservoir in lower crankcase
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveBelt
ClutchWet, multi-plate, Hydraulic Vacuum Assist (HVA) Slipper Action Clutch, hydraulic clutch lever effort
Driveline

Performance

Horespower146.00 HP (106.6 kW)
Torque111.19 Nm (11.3 kgf-m or 82.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity21.19 litres (5.60 gallons)
Emissions

Chassis

Frame TypeAluminum frame, fuel in frame
Rake21.0°
Trail
Front Suspension47 mm Showa inverted forks with adjustable compression damping, rebound damping and spring preload
Front Travel120 mm (4.7 inches)
Rear SuspensionShowa coil over monoshock with adjustable compression damping, rebound damping and spring preload
Rear Travel127 mm (5.0 inches)
Seat
Seat Height
Alt. Seat Height
Total Height
Total Length1,996 mm (78.6 inches)
Total Width716 mm (28.2 inches)
Ground Clearance114 mm (4.5 inches)
Wheelbase1,387 mm (54.6 inches)
Dry Weight170.1 kg (375.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre180/55-ZR17
Front BrakesSingle disc. 8-piston calipers
Front Brake Diameter375 mm (14.8 inches)
Rear BrakesSingle disc. 2-piston calipers
Rear Brake Diameter240 mm (9.4 inches)
Wheels

Comments

It appears you're interested in specifications for the Buell 1125R. This Sport model is powered by a V2, four-stroke engine with 1125.86 ccm (68.70 cubic inches) of actual displacement before 12.3:1 compression. Fueling is metered via Injection. Dual 61 mm down draft throttle bodies, DDFI III fuel injection allowing this machine to produce its 146.00 HP (106.6 kW) horsepower and 111.19 Nm (11.3 kgf-m or 82.0 ft.lbs) torque. According to our records engine heat of the Buell 1125R is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 180/55-ZR17 . The entire package is supported by the frame, Aluminum frame, fuel in frame. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. 8-piston calipers front brakes and Single disc. 2-piston calipers rear brakes. The Buell 1125R was launched in 2008, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
