2008 Honda CRF 230 L Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2008 Honda CRF 230 L.

Basic Specs

Year2008
MakeHonda
ModelHonda CRF 230 L
CostUS$ 4499. Prices depend on country, taxes, accessories, etc.

Engine

Displacement223.00 ccm (13.61 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.0:1
Bore/Stroke65.5 x 66.2 mm (2.6 x 2.6 inches)
Valves/Cylinder
FuelingCarburettor. 30mm CV
IgnitionCDI
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity8.70 litres (2.30 gallons)
Emissions

Chassis

Frame Type
Rake26.8°
Trail103 mm (4.1 inches)
Front Suspension37mm leading-axle Showa fork
Front Travel241 mm (9.5 inches)
Rear SuspensionPro-Link Showa single-shock with spring-preload adjustability
Rear Travel229 mm (9.0 inches)
Seat
Seat Height810 mm (31.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance241 mm (9.5 inches)
Wheelbase1,340 mm (52.8 inches)
Dry Weight121.1 kg (267.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre80/0-21
Rear Tire/Tyre120/80-18
Front BrakesSingle disc
Front Brake Diameter240 mm (9.4 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Honda CRF 230 L. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 223.00 ccm (13.61 cubic inches) of actual displacement before 9.0:1 compression. Fueling is metered via Carburettor. 30mm CV allowing this machine to produce its horsepower and torque. According to our records engine heat of the Honda CRF 230 L is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 80/0-21 and the rear is 120/80-18 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The Honda CRF 230 L was launched in 2008, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model ID: CRF230L
