2008 Kawasaki KLX140 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2008 Kawasaki KLX140.

Basic Specs

Year2008
MakeKawasaki
ModelKawasaki KLX140
CostUS$ 2699. Prices depend on country, taxes, accessories, etc.

Engine

Displacement144.00 ccm (8.79 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.5:1
Bore/Stroke58.0 x 54.4 mm (2.3 x 2.1 inches)
Valves/Cylinder4
FuelingCarburettor. Keihin PB20
IgnitionCDI
Exhaust
LubricationForced, semi-dry sump
CoolingAir

Drivetrain

Gearbox5-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity5.67 litres (1.50 gallons)
Emissions

Chassis

Frame TypeHigh-Tensile steel, box-section perimeter
Rake27.0°
Trail
Front Suspension33mm telescopic fork / 7.1 in.
Front Travel
Rear SuspensionSwingarm with single hydraulic shock / 4.2 in.(KLX140) UNI-TRAK® linkage system and single shock with 5-way preload adjustability / 7.1 in.
Rear Travel
Seat
Seat Height780 mm (30.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,049 mm (41.3 inches)
Total Length1,821 mm (71.7 inches)
Total Width790 mm (31.1 inches)
Ground Clearance236 mm (9.3 inches)
Wheelbase1,260 mm (49.6 inches)
Dry Weight88.0 kg (194.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre70/70-17
Rear Tire/Tyre90/90-14
Front BrakesSingle disc
Front Brake Diameter220 mm (8.7 inches)
Rear BrakesSingle disc
Rear Brake Diameter215 mm (8.5 inches)
Wheels

Comments

It appears you're interested in specifications for the Kawasaki KLX140. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 144.00 ccm (8.79 cubic inches) of actual displacement before 9.5:1 compression. Fueling is metered via Carburettor. Keihin PB20 allowing this machine to produce its horsepower and torque. According to our records engine heat of the Kawasaki KLX140 is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 70/70-17 and the rear is 90/90-14 . The entire package is supported by the frame, High-Tensile steel, box-section perimeter. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The Kawasaki KLX140 was launched in 2008, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
