These are the known mechanical and performance specifications for your 2009 CCM R35.
Basic Specs

Engine
Displacement398.00 ccm (24.29 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression12.2:1
Bore/Stroke90.0 x 62.6 mm (3.5 x 2.5 inches)
Valves/Cylinder
FuelingCarburettor. Keihin FCR39
IgnitionCDI
Exhaust
LubricationDry Sump
CoolingLiquid
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity12.00 litres (3.17 gallons)
Emissions
Chassis
Frame Type
Rake
Trail
Front SuspensionWP 43mm upside down
Front Travel
Rear SuspensionWP PDS
Rear Travel
Seat
Seat Height800 mm (31.5 inches) If adjustable, lowest setting.
Alt. Seat Height830 mm (32.7 inches) If adjustable, highest setting.
Total Height
Total Length
Total Width
Ground Clearance
Wheelbase
Dry Weight128.0 kg (282.2 pounds)
Wet Weight
Wheels & Brakes
Front Tire/Tyre120/70-17
Rear Tire/Tyre150/70-17
Front BrakesSingle disc. Brembo single piston
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. Brembo single piston
Rear Brake Diameter260 mm (10.2 inches)
Wheels
