2009 Highland SuperMotard 450 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2009 Highland SuperMotard 450.

Basic Specs

Year2009
MakeHighland
ModelHighland SuperMotard 450
Cost

Engine

Displacement449.00 ccm (27.40 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke96.0 x 62.1 mm (3.8 x 2.4 inches)
Valves/Cylinder4
FuelingInjection
Ignitioni2 Highland integrated engine management system with ignition coil fitted directly on the spark plug
Exhaust
LubricationWet sump, filter, pressure lubricated crankshaft, camshaft and gearbox
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower56.40 HP (41.2 kW)
Torque51.10 Nm (5.2 kgf-m or 37.7 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity7.00 litres (1.85 gallons)
Emissions

Chassis

Frame TypeHi-tens stainless steel and aluminium swing arrm
Rake25.5°
Trail
Front SuspensionÖhlins/Marzocchi
Front Travel
Rear SuspensionÖhlins shock
Rear Travel
Seat
Seat Height998 mm (39.3 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance350 mm (13.8 inches)
Wheelbase1,485 mm (58.5 inches)
Dry Weight103.0 kg (227.1 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-17
Rear Tire/Tyre160/60-17
Front BrakesSingle disc. Floating disk, six piston caliper
Front Brake Diameter310 mm (12.2 inches)
Rear BrakesSingle disc. Brembo caliper
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Highland SuperMotard 450. This Super motard model is powered by a Single cylinder, four-stroke engine with 449.00 ccm (27.40 cubic inches) of actual displacement before compression. Fueling is metered via Injection allowing this machine to produce its 56.40 HP (41.2 kW) horsepower and 51.10 Nm (5.2 kgf-m or 37.7 ft.lbs) torque. According to our records engine heat of the Highland SuperMotard 450 is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-17 and the rear is 160/60-17 . The entire package is supported by the frame, Hi-tens stainless steel and aluminium swing arrm. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Floating disk, six piston caliper front brakes and Single disc. Brembo caliper rear brakes. The Highland SuperMotard 450 was launched in 2009, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
