2009 Honda Rebel Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2009 Honda Rebel.

Basic Specs

Year2009
MakeHonda
ModelHonda Rebel
CostUS$ 3399. Prices depend on country, taxes, accessories, etc.

Engine

Displacement234.00 ccm (14.28 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression9.2:1
Bore/Stroke53.0 x 53.0 mm (2.1 x 2.1 inches)
Valves/Cylinder2
FuelingCarburettor. Single 26mm diaphragm-type constant-velocity (CV) carburetor
IgnitionCD
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox5-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity9.84 litres (2.60 gallons)
Emissions

Chassis

Frame Type
Rake30.0°
Trail113 mm (4.4 inches)
Front Suspension33mm fork
Front Travel117 mm (4.6 inches)
Rear SuspensionDual shocks with five-position spring-preload adjustability
Rear Travel74 mm (2.9 inches)
Seat
Seat Height676 mm (26.6 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance
Wheelbase1,450 mm (57.1 inches)
Dry Weight
Wet Weight150.1 kg (331.0 pounds)

Wheels & Brakes

Front Tire/Tyre130/18-ZR17
Rear Tire/Tyre130/90-15
Front BrakesDouble disc
Front Brake Diameter
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Honda Rebel. This Custom / cruiser model is powered by a V2, four-stroke engine with 234.00 ccm (14.28 cubic inches) of actual displacement before 9.2:1 compression. Fueling is metered via Carburettor. Single 26mm diaphragm-type constant-velocity (CV) carburetor allowing this machine to produce its horsepower and torque. According to our records engine heat of the Honda Rebel is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 130/18-ZR17 and the rear is 130/90-15 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Expanding brake (drum brake) rear brakes. The Honda Rebel was launched in 2009, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model ID: CMX250C
