2009 Kawasaki KFX 700 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2009 Kawasaki KFX 700.

Basic Specs

Year2009
MakeKawasaki
ModelKawasaki KFX 700
TypeATV
CostUS$ 6849. Prices depend on country, taxes, accessories, etc.

Engine

Displacement697.00 ccm (42.53 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression8.9:1
Bore/Stroke82.0 x 66.0 mm (3.2 x 2.6 inches)
Valves/Cylinder4
FuelingCarburettor. Dual Keihin CVKR-D32
IgnitionSolid state with electronic ignition backup
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveShaft drive (cardan)
ClutchAutomatic
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity12.11 litres (3.20 gallons)
Emissions

Chassis

Frame TypeDouble cradle, racing type, high-tensile tubular steel
Rake
Trail
Front SuspensionDual A-arms, coil-over shocks / 9.3 in.
Front Travel
Rear SuspensionLinkless swingarm, piggy-back reservoir shock, dual-rate spring / 7.9 in.
Rear Travel
Seat
Seat Height851 mm (33.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,171 mm (46.1 inches)
Total Length1,984 mm (78.1 inches)
Total Width1,194 mm (47.0 inches)
Ground Clearance244 mm (9.6 inches)
Wheelbase1,285 mm (50.6 inches)
Dry Weight250.1 kg (551.3 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre22/8-10 (AT)
Rear Tire/Tyre22/11-10 (AT)
Front BrakesDouble disc
Front Brake Diameter
Rear BrakesSealed multidisc
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Kawasaki KFX 700. This ATV model is powered by a V2, four-stroke engine with 697.00 ccm (42.53 cubic inches) of actual displacement before 8.9:1 compression. Fueling is metered via Carburettor. Dual Keihin CVKR-D32 allowing this machine to produce its horsepower and torque. According to our records engine heat of the Kawasaki KFX 700 is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 22/8-10 (AT) and the rear is 22/11-10 (AT) . The entire package is supported by the frame, Double cradle, racing type, high-tensile tubular steel. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Sealed multidisc rear brakes. The Kawasaki KFX 700 was launched in 2009, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Continuously variable transmission with forward, reverse and neutral. Dual 45W halogen headlights, 5/21W taillight/brake light.
