2009 Nipponia Ezio 50 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2009 Nipponia Ezio 50.

Basic Specs

Year2009
MakeNipponia
ModelNipponia Ezio 50
Cost

Engine

Displacement49.60 ccm (3.03 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.1:1
Bore/Stroke38.9 x 41.8 mm (1.5 x 1.6 inches)
Valves/Cylinder
FuelingInjection. Optional carburettor
IgnitionDC CDI
Exhaust
Lubrication
CoolingAir

Drivetrain

GearboxAutomatic
Final DriveBelt
ClutchDry, automatically centrifugal type
Driveline

Performance

Horespower3.75 HP (2.7 kW)
Torque3.70 Nm (0.4 kgf-m or 2.7 ft.lbs)
Top Speed45.0 km/h (28.0 mph)

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity20.81 litres (5.50 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionTelescopic, hydraulic fork
Front Travel
Rear SuspensionDouble hydraulic shock absorbers
Rear Travel
Seat
Seat Height780 mm (30.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,160 mm (45.7 inches)
Total Length1,860 mm (73.2 inches)
Total Width590 mm (23.2 inches)
Ground Clearance
Wheelbase
Dry Weight110.0 kg (242.5 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-13
Rear Tire/Tyre120/70-13
Front BrakesSingle disc
Front Brake Diameter
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Nipponia Ezio 50. This Scooter model is powered by a Single cylinder, four-stroke engine with 49.60 ccm (3.03 cubic inches) of actual displacement before 9.1:1 compression. Fueling is metered via Injection. Optional carburettor allowing this machine to produce its 3.75 HP (2.7 kW) horsepower and 3.70 Nm (0.4 kgf-m or 2.7 ft.lbs) torque. According to our records engine heat of the Nipponia Ezio 50 is moderated by Air. You'll need to get familiar with the Automatic transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 120/70-13 and the rear is 120/70-13 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Expanding brake (drum brake) rear brakes. The Nipponia Ezio 50 was launched in 2009, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
