2009 Skyteam ST250 SM Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2009 Skyteam ST250 SM.

Basic Specs

Year2009
MakeSkyteam
ModelSkyteam ST250 SM
TypeEnduro / offroad
Cost
Service Manual
Classic Service Manual
Electric Service Manual

Engine

Displacement223.00 ccm (13.61 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.0:1
Bore/Stroke39.0 x 41.4 mm (1.5 x 1.6 inches)
Valves/Cylinder
Fueling
IgnitionCDI
Exhaust
LubricationPressure and splash lubricarion
CoolingAir
Spark Plugs

Drivetrain

Gearbox5-speed
Final DriveChain
Clutch
Driveline
Chain Clutch Plates

Performance

Horespower12.00 HP (8.8 kW)
Torque
Top Speed106.0 km/h (65.9 mph)
K&N Air Filter Slip-on Exhaust

Fuel Economy & Polution

Fuel Consumption2.90 litres/100 km (34.5 km/l or 81.11 mpg)
Fuel Capacity10.00 litres (2.64 gallons)
Emissions67.3 CO2 g/km. (CO2 - Carbon dioxide emission)
Fuel Bottles & Cans

Chassis

Frame Type
Rake
Trail
Front SuspensionSpring and oil
Front Travel
Rear SuspensionGas/monoshock
Rear Travel
Seat
Seat Height910 mm (35.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,230 mm (48.4 inches)
Total Length2,150 mm (84.6 inches)
Total Width830 mm (32.7 inches)
Ground Clearance
Wheelbase
Dry Weight123.0 kg (271.2 pounds)
Wet Weight
Seats & Covers Lowering Kits Titanium

Wheels & Brakes

Front Tire/Tyre100/90-10
Rear Tire/Tyre120/90-10
Front BrakesSingle disc
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter
Wheels
Front Brakes Pads Rear Brake Pads Front Tire Rear Tire

Comments

It appears you're interested in specifications for the Skyteam ST250 SM. This Enduro / offroad model is powered by a Single cylinder, four-stroke engine with 223.00 ccm (13.61 cubic inches) of actual displacement before 9.0:1 compression. Fueling is metered via allowing this machine to produce its 12.00 HP (8.8 kW) horsepower and torque. According to our records engine heat of the Skyteam ST250 SM is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 100/90-10 and the rear is 120/90-10 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The Skyteam ST250 SM was launched in 2009, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Made in China.
