2009 Vespa GTS 250ie Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2009 Vespa GTS 250ie.

Basic Specs

Year2009
MakeVespa
ModelVespa GTS 250ie
CostUS$ 5999. Prices depend on country, taxes, accessories, etc.

Engine

Displacement244.00 ccm (14.89 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke72.0 x 60.0 mm (2.8 x 2.4 inches)
Valves/Cylinder4
FuelingInjection. Port injected Alfa/N type with lambda closed loop control and three way catalytic converter.
IgnitionElectronic by capacitive discharge (CDI)
Exhaust
LubricationWet sump, chain-driven lobe pump, filtration during aspiration and discharge
CoolingLiquid

Drivetrain

GearboxAutomatic
Final Drive
ClutchDry, centrifugal type
Driveline

Performance

Horespower21.30 HP (15.5 kW)
Torque20.10 Nm (2.0 kgf-m or 14.8 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity9.20 litres (2.43 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionSingle-sided trailing arm with dual chamber hydraulic shock absorber with coaxial spring.
Front Travel
Rear SuspensionHelical spring with adjustable four-position pre-load and two dual effect hydraulic shock absorbers.
Rear Travel
Seat
Seat Height
Alt. Seat Height
Total Height
Total Length1,930 mm (76.0 inches)
Total Width
Ground Clearance
Wheelbase1,370 mm (53.9 inches)
Dry Weight151.0 kg (332.9 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-12
Rear Tire/Tyre130/70-12
Front BrakesSingle disc
Front Brake Diameter220 mm (8.7 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Vespa GTS 250ie. This Scooter model is powered by a Single cylinder, four-stroke engine with 244.00 ccm (14.89 cubic inches) of actual displacement before compression. Fueling is metered via Injection. Port injected Alfa/N type with lambda closed loop control and three way catalytic converter. allowing this machine to produce its 21.30 HP (15.5 kW) horsepower and 20.10 Nm (2.0 kgf-m or 14.8 ft.lbs) torque. According to our records engine heat of the Vespa GTS 250ie is moderated by Liquid. You'll need to get familiar with the Automatic transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 120/70-12 and the rear is 130/70-12 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The Vespa GTS 250ie was launched in 2009, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
