2009 Yamaha FZ1 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2009 Yamaha FZ1.

Basic Specs

Year2009
MakeYamaha
ModelYamaha FZ1
CostUS$ 9790. Prices depend on country, taxes, accessories, etc.

Engine

Displacement998.00 ccm (60.90 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression11.5:1
Bore/Stroke77.0 x 53.6 mm (3.0 x 2.1 inches)
Valves/Cylinder4
FuelingInjection
IgnitionTCI: Transistor Controlled Ignition
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption6.72 litres/100 km (14.9 km/l or 35.00 mpg)
Fuel Capacity17.97 litres (4.75 gallons)
Emissions155.9 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake25.0°
Trail109 mm (4.3 inches)
Front Suspension43mm fork
Front Travel130 mm (5.1 inches)
Rear SuspensionSingle shock
Rear Travel130 mm (5.1 inches)
Seat
Seat Height815 mm (32.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,204 mm (47.4 inches)
Total Length2,141 mm (84.3 inches)
Total Width770 mm (30.3 inches)
Ground Clearance
Wheelbase1,461 mm (57.5 inches)
Dry Weight
Wet Weight220.0 kg (485.0 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre190/50-ZR17
Front BrakesDouble disc
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc
Rear Brake Diameter245 mm (9.6 inches)
Wheels

Comments

It appears you're interested in specifications for the Yamaha FZ1. This Naked bike model is powered by a In-line four, four-stroke engine with 998.00 ccm (60.90 cubic inches) of actual displacement before 11.5:1 compression. Fueling is metered via Injection allowing this machine to produce its horsepower and torque. According to our records engine heat of the Yamaha FZ1 is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 190/50-ZR17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Yamaha FZ1 was launched in 2009, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
