These are the known mechanical and performance specifications for your 2009 Yamaha FZ1.
Basic Specs
Year2009
MakeYamaha
ModelYamaha FZ1
TypeNaked bike
CostUS$ 9790. Prices depend on country, taxes, accessories, etc.
Engine
Displacement998.00 ccm (60.90 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression11.5:1
Bore/Stroke77.0 x 53.6 mm (3.0 x 2.1 inches)
Valves/Cylinder4
FuelingInjection
IgnitionTCI: Transistor Controlled Ignition
Exhaust
Lubrication
CoolingLiquid
Fuel Economy & Polution
Fuel Consumption6.72 litres/100 km (14.9 km/l or 35.00 mpg)
Fuel Capacity17.97 litres (4.75 gallons)
Emissions155.9 CO2 g/km. (CO2 - Carbon dioxide emission)
Chassis
Frame Type
Rake25.0°
Trail109 mm (4.3 inches)
Front Suspension43mm fork
Front Travel130 mm (5.1 inches)
Rear SuspensionSingle shock
Rear Travel130 mm (5.1 inches)
Seat
Seat Height815 mm (32.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,204 mm (47.4 inches)
Total Length2,141 mm (84.3 inches)
Total Width770 mm (30.3 inches)
Ground Clearance
Wheelbase1,461 mm (57.5 inches)
Dry Weight
Wet Weight220.0 kg (485.0 pounds)
Wheels & Brakes
Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre190/50-ZR17
Front BrakesDouble disc
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc
Rear Brake Diameter245 mm (9.6 inches)
Wheels
