2009 Yamaha FZS Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2009 Yamaha FZS.

Basic Specs

Year2009
MakeYamaha
ModelYamaha FZS
CostUS$ 1360. Prices depend on country, taxes, accessories, etc.

Engine

Displacement153.00 ccm (9.34 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM12000
Compression9.0:1
Bore/Stroke58.0 x 57.9 mm (2.3 x 2.3 inches)
Valves/Cylinder2
FuelingCarburettor. Type BS26 Carb
IgnitionCDI
ExhaustSingle midship with plastic cover
LubricationWet sump
CoolingAir

Drivetrain

Gearbox5-speed
Final DriveChain
ClutchConstant mesh wet multiplate
Driveline

Performance

Horespower14.00 HP (10.2 kW)
Torque14.00 Nm (1.4 kgf-m or 10.3 ft.lbs)
Top Speed130.0 km/h (80.8 mph)

Fuel Economy & Polution

Fuel Consumption2.50 litres/100 km (40.0 km/l or 94.09 mpg)
Fuel Capacity14.00 litres (3.70 gallons)
Emissions58.0 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeDiamond
Rake
Trail
Front Suspensiontelescopic
Front Travel120 mm (4.7 inches)
Rear Suspensionmonocross
Rear Travel120 mm (4.7 inches)
Seat
Seat Height790 mm (31.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,045 mm (41.1 inches)
Total Length1,975 mm (77.8 inches)
Total Width770 mm (30.3 inches)
Ground Clearance160 mm (6.3 inches)
Wheelbase1,335 mm (52.6 inches)
Dry Weight126.0 kg (277.8 pounds)
Wet Weight137.0 kg (302.0 pounds)

Wheels & Brakes

Front Tire/Tyre100/80-17
Rear Tire/Tyre140/60-R17
Front BrakesSingle disc. 2 piston hydraulic
Front Brake Diameter267 mm (10.5 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Yamaha FZS. This Naked bike model is powered by a Single cylinder, four-stroke engine with 153.00 ccm (9.34 cubic inches) of actual displacement before 9.0:1 compression. Fueling is metered via Carburettor. Type BS26 Carb allowing this machine to produce its 14.00 HP (10.2 kW) horsepower and 14.00 Nm (1.4 kgf-m or 10.3 ft.lbs) torque. According to our records engine heat of the Yamaha FZS is moderated by Air. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 100/80-17 and the rear is 140/60-R17 . The entire package is supported by the frame, Diamond. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. 2 piston hydraulic front brakes and Expanding brake (drum brake) rear brakes. The Yamaha FZS was launched in 2009, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
