These are the known mechanical and performance specifications for your 2010 Sherco SX 2.5i -F.
Basic Specs
Engine
Displacement250.00 ccm (15.26 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke78.0 x 52.2 mm (3.1 x 2.1 inches)
Valves/Cylinder4
FuelingInjection. Electronic intake pipe injection/digital engine management: Magnetti Marelli
Ignition
ExhaustEuro 3. Stainless steel header pipe and muffler with catalytic converter.
LubricationDry sump
CoolingLiquid
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity7.50 litres (1.98 gallons)
Emissions
Chassis
Frame TypeSimple Chrome-Molybdenum and aluminium double cradle design
Rake
Trail
Front SuspensionOhlins telescopic fork, Ø48 mm tubes rebound and compression adjustable
Front Travel295 mm (11.6 inches)
Rear SuspensionOhlins progressive, multiadjustable rear shock utilizing a linkage and rod system
Rear Travel320 mm (12.6 inches)
Seat
Seat Height900 mm (35.4 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance385 mm (15.2 inches)
Wheelbase1,485 mm (58.5 inches)
Dry Weight102.0 kg (224.9 pounds)
Wet Weight
Wheels & Brakes
Front Tire/Tyre1.60-21
Rear Tire/Tyre2.15-18
Front BrakesSingle disc
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter
Wheels
Comments
