2011 Confederate B120 Wraith Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2011 Confederate B120 Wraith.

Basic Specs

Year2011
MakeConfederate
ModelConfederate B120 Wraith
Cost

Engine

Displacement1966.00 ccm (119.97 cubic inches)
TypeJims/Confederate B120 counter balanced twin cam 45 degree radial twin
DetailsV2, four-stroke
Max RPM
Compression
Bore/Stroke104.8 x 114.3 mm (4.1 x 4.5 inches)
Valves/Cylinder
FuelingInjection
Ignition
Exhaust
Lubrication
Cooling

Drivetrain

Gearbox5-speed
Final DriveBelt
Clutch
Driveline

Performance

Horespower125.00 HP (91.2 kW)
Torque176.28 Nm (18.0 kgf-m or 130.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity
Emissions

Chassis

Frame TypeConfederate design triple load path carbon fiber monocoque. Aircraft grade CNC billet bulkhead, fuselage. Oil in frame.
Rake27.0°
Trail
Front SuspensionDouble wishbone, machined from aircraft grade billet aluminum, linked to aerodynamically designed carbon fiber wing blades
Front Travel
Rear SuspensionSingle sided aircraft grade aluminum swing arm
Rear Travel
Seat
Seat Height775 mm (30.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance
Wheelbase
Dry Weight176.9 kg (390.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/60-17
Rear Tire/Tyre280/55-17
Front BrakesDouble disc. Bremo, 4-piston
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. Bremo, 2-piston
Rear Brake Diameter220 mm (8.7 inches)
WheelsCarbon fiber; Front: 3.5 in X 17 in; Rear: 5.75 in x 17 in

Comments

It appears you're interested in specifications for the Confederate B120 Wraith. This Naked bike model is powered by a Jims/Confederate B120 counter balanced twin cam 45 degree radial twin V2, four-stroke engine with 1966.00 ccm (119.97 cubic inches) of actual displacement before compression. Fueling is metered via Injection allowing this machine to produce its 125.00 HP (91.2 kW) horsepower and 176.28 Nm (18.0 kgf-m or 130.0 ft.lbs) torque. According to our records engine heat of the Confederate B120 Wraith is moderated by . You'll need to get familiar with the 5-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 120/60-17 and the rear is 280/55-17 . The entire package is supported by the frame, Confederate design triple load path carbon fiber monocoque. Aircraft grade CNC billet bulkhead, fuselage. Oil in frame.. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Bremo, 4-piston front brakes and Single disc. Bremo, 2-piston rear brakes. The Confederate B120 Wraith was launched in 2011, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Limited edition of 250 bikes.
