These are the known mechanical and performance specifications for your 2011 Honda VTX1800F.
Basic Specs
Year2011
MakeHonda
ModelHonda VTX1800F
TypeCustom / cruiser
CostUS$ 13499. Prices depend on country, taxes, accessories, etc.
Engine
Displacement1795.00 ccm (109.53 cubic inches)
Type52° V-twin
DetailsV2, four-stroke
Max RPM
Compression9.0:1
Bore/Stroke101.0 x 112.0 mm (4.0 x 4.4 inches)
Valves/Cylinder3
FuelingInjection. PGM-FI with automatic choke
IgnitionDigital, two spark plugs per cylinder
Exhaust
Lubrication
CoolingLiquid
Drivetrain
Gearbox5-speed
Final DriveShaft drive (cardan)
Clutch
Driveline
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity18.17 litres (4.80 gallons)
Emissions
Chassis
Frame Type
Rake31.5°
Trail144 mm (5.7 inches)
Front Suspension45mm inverted fork
Front Travel109 mm (4.3 inches)
Rear SuspensionDual shocks with five-position spring preload adjustability
Rear Travel99 mm (3.9 inches)
Seat
Seat Height701 mm (27.6 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance
Wheelbase1,669 mm (65.7 inches)
Dry Weight
Wet Weight351.1 kg (774.0 pounds)
Wheels & Brakes
Front Tire/Tyre130/70-R18
Rear Tire/Tyre180/55-R18
Front BrakesDouble disc
Front Brake Diameter296 mm (11.7 inches)
Rear BrakesSingle disc
Rear Brake Diameter316 mm (12.4 inches)
Wheels
Comments
Model ID: VTX1800F1
