2011 Moto Guzzi Bellagio Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2011 Moto Guzzi Bellagio.

Basic Specs

Year2011
MakeMoto Guzzi
ModelMoto Guzzi Bellagio
Cost Euro 10760. UK £ 7799. Prices depend on country, taxes, accessories, etc.

Engine

Displacement935.60 ccm (57.09 cubic inches)
Type
DetailsV2, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke95.0 x 66.0 mm (3.7 x 2.6 inches)
Valves/Cylinder2
FuelingInjection
Ignition
Exhaust2 inti 1 into 2
Lubrication
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveShaft drive (cardan)
ClutchDry mechanically operated twin plate
Driveline

Performance

Horespower75.00 HP (54.7 kW)
Torque75.00 Nm (7.6 kgf-m or 55.3 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity19.00 litres (5.02 gallons)
Emissions

Chassis

Frame TypeVery rigid high tensile steel tubular twin cradle
Rake
Trail
Front SuspensionMarzocchi 45 mm adjustable front forks
Front Travel140 mm (5.5 inches)
Rear SuspensionSingle swingarm with progressive action and ndash
Rear Travel120 mm (4.7 inches)
Seat
Seat Height760 mm (29.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,130 mm (44.5 inches)
Total Length2,253 mm (88.7 inches)
Total Width
Ground Clearance150 mm (5.9 inches)
Wheelbase1,560 mm (61.4 inches)
Dry Weight223.0 kg (491.6 pounds)
Wet Weight238.0 kg (524.7 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR18
Rear Tire/Tyre180/55-ZR17
Front BrakesDouble disc. Stainless steel discs, floating Brembo calipers with 2 parallel pistons.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. Fixed stainless steel disc, floating Brembo calipers with 2 parallel pistons.
Rear Brake Diameter282 mm (11.1 inches)
Wheels

Comments

It appears you're interested in specifications for the Moto Guzzi Bellagio. This Custom / cruiser model is powered by a V2, four-stroke engine with 935.60 ccm (57.09 cubic inches) of actual displacement before 10.0:1 compression. Fueling is metered via Injection allowing this machine to produce its 75.00 HP (54.7 kW) horsepower and 75.00 Nm (7.6 kgf-m or 55.3 ft.lbs) torque. According to our records engine heat of the Moto Guzzi Bellagio is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 120/70-ZR18 and the rear is 180/55-ZR17 . The entire package is supported by the frame, Very rigid high tensile steel tubular twin cradle. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Stainless steel discs, floating Brembo calipers with 2 parallel pistons. front brakes and Single disc. Fixed stainless steel disc, floating Brembo calipers with 2 parallel pistons. rear brakes. The Moto Guzzi Bellagio was launched in 2011, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
