2011 Victory Arlen Ness Vision Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2011 Victory Arlen Ness Vision.

Basic Specs

Year2011
MakeVictory
ModelVictory Arlen Ness Vision
CostUS$ 27999. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1731.00 ccm (105.63 cubic inches)
TypeSingle overhead camshafts with 4 valves per cylinder, self-adjusting cam chains, hydraulic lifters
DetailsV2, four-stroke
Max RPM
Compression9.4:1
Bore/Stroke101.0 x 108.0 mm (4.0 x 4.3 inches)
Valves/Cylinder4
FuelingInjection. 45mm throttle bodies
Ignition
ExhaustSplit dual exhaust with crossover
Lubrication
CoolingOil & air

Drivetrain

Gearbox6-speed
Final DriveBelt
ClutchWet, multiplate
Driveline

Performance

Horespower97.00 HP (70.8 kW)
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity17.03 litres (4.50 gallons)
Emissions

Chassis

Frame Type
Rake29.0°
Trail137 mm (5.4 inches)
Front SuspensionConventional telescopic fork, 43mm diameter
Front Travel130 mm (5.1 inches)
Rear SuspensionSingle, mono-tube gas,cast aluminum with rising rate linkage, preload adjustable spring
Rear Travel93 mm (3.6 inches)
Seat
Seat Height673 mm (26.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,629 mm (103.5 inches)
Total Width
Ground Clearance147 mm (5.8 inches)
Wheelbase1,670 mm (65.7 inches)
Dry Weight395.0 kg (870.8 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre130/70-R18
Rear Tire/Tyre180/60-R18
Front BrakesDouble disc. 300mm floating rotors with 4-piston calipers. Anti-locking brakes.
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. Floating rotor with 2-piston caliper
Rear Brake Diameter300 mm (11.8 inches)
Wheels

Comments

It appears you're interested in specifications for the Victory Arlen Ness Vision. This Custom / cruiser model is powered by a Single overhead camshafts with 4 valves per cylinder, self-adjusting cam chains, hydraulic lifters V2, four-stroke engine with 1731.00 ccm (105.63 cubic inches) of actual displacement before 9.4:1 compression. Fueling is metered via Injection. 45mm throttle bodies allowing this machine to produce its 97.00 HP (70.8 kW) horsepower and torque. According to our records engine heat of the Victory Arlen Ness Vision is moderated by Oil & air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 130/70-R18 and the rear is 180/60-R18 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. 300mm floating rotors with 4-piston calipers. Anti-locking brakes. front brakes and Single disc. Floating rotor with 2-piston caliper rear brakes. The Victory Arlen Ness Vision was launched in 2011, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
