2011 Victory Vision 8 Ball Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2011 Victory Vision 8 Ball.

Basic Specs

Year2011
MakeVictory
ModelVictory Vision 8 Ball
CostUS$ 17999. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1731.00 ccm (105.63 cubic inches)
Type50 degree V-Twin. self-adjusting cam chains, hydraulic lifters.
DetailsV2, four-stroke
Max RPM
Compression9.4:1
Bore/Stroke101.0 x 108.0 mm (4.0 x 4.3 inches)
Valves/Cylinder4
FuelingInjection
Ignition
ExhaustSplit dual exhaust with crossover
Lubrication
CoolingOil & air

Drivetrain

Gearbox6-speed
Final DriveBelt
Clutch
DrivelinePrimary Drive: Gear drive with torque compensator. Final Drive: Carbon Fiber Reinforced Belt.

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity22.71 litres (6.00 gallons)
Emissions

Chassis

Frame Type
Rake29.0°
Trail142 mm (5.6 inches)
Front SuspensionConventional telescopic fork, 46 mm diameter
Front Travel130 mm (5.1 inches)
Rear SuspensionSingle, mono-tube gas,cast aluminum with rising rate linkage
Rear Travel93 mm (3.6 inches)
Seat
Seat Height622 mm (24.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length26,296 mm (1,035.3 inches)
Total Width
Ground Clearance122 mm (4.8 inches)
Wheelbase1,670 mm (65.7 inches)
Dry Weight364.0 kg (802.5 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre130/70-18
Rear Tire/Tyre180/60-16
Front BrakesDouble disc. Dual 300mm floating rotors with 4-piston calipers. Linked.
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. 300mm floating rotor with 2-piston caliper
Rear Brake Diameter300 mm (11.8 inches)
Wheels

Comments

It appears you're interested in specifications for the Victory Vision 8 Ball. This Custom / cruiser model is powered by a 50 degree V-Twin. self-adjusting cam chains, hydraulic lifters. V2, four-stroke engine with 1731.00 ccm (105.63 cubic inches) of actual displacement before 9.4:1 compression. Fueling is metered via Injection allowing this machine to produce its horsepower and torque. According to our records engine heat of the Victory Vision 8 Ball is moderated by Oil & air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 130/70-18 and the rear is 180/60-16 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Dual 300mm floating rotors with 4-piston calipers. Linked. front brakes and Single disc. 300mm floating rotor with 2-piston caliper rear brakes. The Victory Vision 8 Ball was launched in 2011, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
