2011 Yamaha FJR1300A Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2011 Yamaha FJR1300A.

Basic Specs

Year2011
MakeYamaha
ModelYamaha FJR1300A
CostUS$ 15490. Euro 16795. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1298.00 ccm (79.20 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression10.8:1
Bore/Stroke79.0 x 66.2 mm (3.1 x 2.6 inches)
Valves/Cylinder4
FuelingInjection
IgnitionTCI: Transistor Controlled Ignition
Exhaust
LubricationWet sump
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveShaft drive (cardan)
ClutchMultiplate wet clutch
Driveline

Performance

Horespower140.81 HP (102.8 kW)
Torque134.00 Nm (13.7 kgf-m or 98.8 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption6.03 litres/100 km (16.6 km/l or 39.01 mpg)
Fuel Capacity24.98 litres (6.60 gallons)
Emissions139.9 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake26.0°
Trail109 mm (4.3 inches)
Front Suspension48mm fork
Front Travel135 mm (5.3 inches)
Rear SuspensionSingle shock
Rear Travel124 mm (4.9 inches)
Seat
Seat Height805 mm (31.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,450 mm (57.1 inches)
Total Length2,230 mm (87.8 inches)
Total Width749 mm (29.5 inches)
Ground Clearance130 mm (5.1 inches)
Wheelbase1,544 mm (60.8 inches)
Dry Weight
Wet Weight292.1 kg (644.0 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre180/55-ZR17
Front BrakesDouble disc
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc
Rear Brake Diameter282 mm (11.1 inches)
Wheels

Comments

It appears you're interested in specifications for the Yamaha FJR1300A. This Sport touring model is powered by a In-line four, four-stroke engine with 1298.00 ccm (79.20 cubic inches) of actual displacement before 10.8:1 compression. Fueling is metered via Injection allowing this machine to produce its 140.81 HP (102.8 kW) horsepower and 134.00 Nm (13.7 kgf-m or 98.8 ft.lbs) torque. According to our records engine heat of the Yamaha FJR1300A is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 180/55-ZR17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Yamaha FJR1300A was launched in 2011, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
