These are the known mechanical and performance specifications for your 2012 Husqvarna WR250.
Basic Specs
Year2012
MakeHusqvarna
ModelHusqvarna WR250
TypeEnduro / offroad
CostUS$ 6799. Prices depend on country, taxes, accessories, etc.
Engine
Displacement249.30 ccm (15.21 cubic inches)
TypePower valve with mechanical control on the exhaust port.
DetailsSingle cylinder, two-stroke
Max RPM
Compression
Bore/Stroke66.4 x 72.0 mm (2.6 x 2.8 inches)
Valves/Cylinder
FuelingCarburettor. Mikuni TMX38 Carburettor
Ignition
Exhaust
LubricationFuel/oil pre-mix of 50:1
CoolingLiquid
Drivetrain
Gearbox5-speed
Final DriveChain
ClutchMulti plate, cable operation
DrivelineConstant mesh
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity9.46 litres (2.50 gallons)
Emissions
Chassis
Frame TypeChromoly steel single-tube frame cradle (round tubes); aluminum alloy sub frame
Rake27.0°
Trail100 mm (3.9 inches)
Front SuspensionKayaba 48mm open cartridge fork with fully-adjustable compression and rebound damping. Upside down (USD) fork.
Front Travel300 mm (11.8 inches)
Rear SuspensionSachs single shock with remote reservoir, adjustable spring preload, compression and rebound damping.
Rear Travel320 mm (12.6 inches)
Seat
Seat Height985 mm (38.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,260 mm (89.0 inches)
Total Width840 mm (33.1 inches)
Ground Clearance345 mm (13.6 inches)
Wheelbase1,485 mm (58.5 inches)
Dry Weight107.0 kg (235.9 pounds)
Wet Weight
Wheels & Brakes
Front Tire/Tyre90/90-21
Rear Tire/Tyre140/80-18
Front BrakesSingle disc
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels
