2012 Johnny Pag Malibu Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2012 Johnny Pag Malibu.

Basic Specs

Year2012
MakeJohnny Pag
ModelJohnny Pag Malibu
CostUS$ 5199. Prices depend on country, taxes, accessories, etc.

Engine

Displacement320.00 ccm (19.53 cubic inches)
Type
DetailsTwin, four-stroke
Max RPM
Compression10.5:1
Bore/Stroke53.0 x 62.0 mm (2.1 x 2.4 inches)
Valves/Cylinder2
FuelingCarburettor. Dual 26mm Keihin Vacuum Carburetor
Ignition
ExhaustStainless Steel, single sided exhaust
LubricationForced Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final Drive
Clutch
Driveline

Performance

Horespower22.00 HP (16.1 kW)
Torque
Top Speed172.2 km/h (107.0 mph)

Fuel Economy & Polution

Fuel Consumption3.46 litres/100 km (28.9 km/l or 67.98 mpg)
Fuel Capacity17.94 litres (4.74 gallons)
Emissions80.3 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeSeamless steel tubing
Rake38.0°
Trail
Front Suspension39 mm conventional forks
Front Travel
Rear SuspensionDual shocks, fully-adjustable.
Rear Travel
Seat
Seat Height508 mm (20.0 inches) If adjustable, lowest setting.
Alt. Seat Height584 mm (23.0 inches) If adjustable, highest setting.
Total Height
Total Length
Total Width
Ground Clearance152 mm (6.0 inches)
Wheelbase1,702 mm (67.0 inches)
Dry Weight
Wet Weight189.6 kg (418.0 pounds)

Wheels & Brakes

Front Tire/Tyre90/90-21
Rear Tire/Tyre140/70-18
Front BrakesDouble disc. 2-piston
Front Brake Diameter
Rear BrakesSingle disc. 2-piston
Rear Brake Diameter
WheelsStainless Steel Spoked rims with T6 6061 billet hubs

Comments

It appears you're interested in specifications for the Johnny Pag Malibu. This Custom / cruiser model is powered by a Twin, four-stroke engine with 320.00 ccm (19.53 cubic inches) of actual displacement before 10.5:1 compression. Fueling is metered via Carburettor. Dual 26mm Keihin Vacuum Carburetor allowing this machine to produce its 22.00 HP (16.1 kW) horsepower and torque. According to our records engine heat of the Johnny Pag Malibu is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive maintainence. Our best information shows that the front tire size is 90/90-21 and the rear is 140/70-18 . The entire package is supported by the frame, Seamless steel tubing. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. 2-piston front brakes and Single disc. 2-piston rear brakes. The Johnny Pag Malibu was launched in 2012, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
