These are the known mechanical and performance specifications for your 2012 Suzuki Boulevard M109R.
Basic Specs


Year2012
MakeSuzuki
ModelSuzuki Boulevard M109R
TypeCustom / cruiser
CostUS$ 14299. Prices depend on country, taxes, accessories, etc.
Engine
Displacement1783.00 ccm (108.80 cubic inches)
Type54° V-twin. Forged aluminum-alloy pistons.
DetailsV2, four-stroke
Max RPM
Compression10.5:1
Bore/Stroke112.0 x 90.5 mm (4.4 x 3.6 inches)
Valves/Cylinder4
FuelingInjection. Suzuki Dual Throttle Valve system (SDTV) with 52mm throttle bodies
IgnitionTransistorized
Exhaust2-into1-into2 stainless steel chromed
Lubrication
CoolingLiquid
Drivetrain
Gearbox5-speed
Final DriveShaft drive (cardan)
Clutch
Driveline5-speed constant mesh
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity19.50 litres (5.15 gallons)
Emissions
Chassis
Frame TypeHigh-tensile double cradle steel
Rake
Trail
Front SuspensionTelescopic, coil spring, oil damped
Front Travel130 mm (5.1 inches)
Rear SuspensionLink type, coil spring, oil damped
Rear Travel
Seat
Seat Height705 mm (27.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,450 mm (96.5 inches)
Total Width875 mm (34.4 inches)
Ground Clearance130 mm (5.1 inches)
Wheelbase1,710 mm (67.3 inches)
Dry Weight
Wet Weight347.0 kg (765.0 pounds)
Wheels & Brakes
Front Tire/Tyre150/80-R16
Rear Tire/Tyre240/55-R16
Front BrakesDouble disc
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter
Wheels
Comments
