These are the known mechanical and performance specifications for your 2012 Yamaha TT-R125LE.
Basic Specs
Year2012
MakeYamaha
ModelYamaha TT-R125LE
TypeEnduro / offroad
CostUS$ 3190. Prices depend on country, taxes, accessories, etc.
Engine
Displacement124.00 ccm (7.57 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.0:1
Bore/Stroke54.0 x 54.0 mm (2.1 x 2.1 inches)
Valves/Cylinder2
FuelingCarburettor. Mikuni VM20
IgnitionCDI
Exhaust
LubricationWet, multidisc
CoolingAir
Drivetrain
Gearbox5-speed
Final DriveChain
Clutch
DrivelineConstant-mesh 5-speed
Fuel Economy & Polution
Fuel Consumption
Fuel Capacity6.06 litres (1.60 gallons)
Emissions
Chassis
Frame Type
Rake
Trail
Front SuspensionTelescopic fork
Front Travel180 mm (7.1 inches)
Rear SuspensionSingle shock
Rear Travel168 mm (6.6 inches)
Seat
Seat Height805 mm (31.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,085 mm (42.7 inches)
Total Length1,885 mm (74.2 inches)
Total Width795 mm (31.3 inches)
Ground Clearance295 mm (11.6 inches)
Wheelbase1,270 mm (50.0 inches)
Dry Weight
Wet Weight89.8 kg (198.0 pounds)
Wheels & Brakes
Front Tire/Tyre70/100-19
Rear Tire/Tyre90/100-16
Front BrakesSingle disc
Front Brake Diameter220 mm (8.7 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter110 mm (4.3 inches)
Wheels
