2013 Harley-Davidson CVO Road King 110th Anniversary Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2013 Harley-Davidson CVO Road King 110th Anniversary.

Basic Specs

Year2013
MakeHarley-Davidson
ModelHarley-Davidson CVO Road King 110th Anniversary
CostUS$ 30999. Euro 32525. UK £ 26295. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1802.69 ccm (110.00 cubic inches)
TypeAir-cooled, Twin Cam 110™
DetailsV2, four-stroke
Max RPM
Compression9.2:1
Bore/Stroke101.6 x 111.3 mm (4.0 x 4.4 inches)
Valves/Cylinder
FuelingInjection. Electronic Sequential Port Fuel Injection
Ignition
ExhaustChrome dual exhaust with 4 in. touring mufflers and touring muffler shields
LubricationDry-sump
CoolingAir

Drivetrain

Gearbox6-speed
Final DriveBelt
ClutchMulti-plate with diaphragm spring in oil bath
Driveline

Performance

Horespower
Torque160.01 Nm (16.3 kgf-m or 118.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption5.74 litres/100 km (17.4 km/l or 40.98 mpg)
Fuel Capacity22.71 litres (6.00 gallons)
Emissions133.2 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake26.0°
Trail170 mm (6.7 inches)
Front Suspension
Front Travel
Rear Suspension
Rear Travel
Seat
Seat Height673 mm (26.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,456 mm (96.7 inches)
Total Width
Ground Clearance124 mm (4.9 inches)
Wheelbase1,626 mm (64.0 inches)
Dry Weight367.0 kg (809.0 pounds)
Wet Weight380.1 kg (838.0 pounds)

Wheels & Brakes

Front Tire/Tyre130/80-NW17
Rear Tire/Tyre180/65-NW16
Front BrakesDouble disc
Front Brake Diameter
Rear BrakesSingle disc
Rear Brake Diameter
WheelsMirror Chrome Agitator Custom Wheels

Comments

It appears you're interested in specifications for the Harley-Davidson CVO Road King 110th Anniversary. This Touring model is powered by a Air-cooled, Twin Cam 110™ V2, four-stroke engine with 1802.69 ccm (110.00 cubic inches) of actual displacement before 9.2:1 compression. Fueling is metered via Injection. Electronic Sequential Port Fuel Injection allowing this machine to produce its horsepower and 160.01 Nm (16.3 kgf-m or 118.0 ft.lbs) torque. According to our records engine heat of the Harley-Davidson CVO Road King 110th Anniversary is moderated by Air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 130/80-NW17 and the rear is 180/65-NW16 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Single disc rear brakes. The Harley-Davidson CVO Road King 110th Anniversary was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Special Edition celebrating HD´s 110th Anniversary. CVO is HD´s Custom Vehicle Operation.
