2013 Honda VT1300CS Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2013 Honda VT1300CS.

Basic Specs

Year2013
MakeHonda
ModelHonda VT1300CS
Cost

Engine

Displacement1312.00 ccm (80.06 cubic inches)
Type52° V-twin
DetailsV2, four-stroke
Max RPM
Compression9.2:1
Bore/Stroke89.5 x 104.3 mm (3.5 x 4.1 inches)
Valves/Cylinder4
FuelingInjection. PGM-FI with automatic enricher circuit
IgnitionDigital with 3-dimensional mapping, 2 sparks per cylinder
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveShaft drive (cardan)
Clutch
Driveline

Performance

Horespower56.99 HP (41.6 kW)
Torque107.00 Nm (10.9 kgf-m or 78.9 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption4.93 litres/100 km (20.3 km/l or 47.71 mpg)
Fuel Capacity20.30 litres (5.36 gallons)
Emissions114.4 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake
Trail
Front Suspension45mm telescopic fork with 130mm stroke and 102.4mm axle travel
Front Travel
Rear SuspensionMonoshock with adjustable rebound damping and 35-position spring preload adjustability, 95mm axle travel
Rear Travel
Seat
Seat Height678 mm (26.7 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,150 mm (45.3 inches)
Total Length2,575 mm (101.4 inches)
Total Width900 mm (35.4 inches)
Ground Clearance126 mm (5.0 inches)
Wheelbase1,805 mm (71.1 inches)
Dry Weight309.0 kg (681.2 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre90/90-21
Rear Tire/Tyre200/50-18
Front BrakesDouble disc. ABS. Twin-piston caliper
Front Brake Diameter336 mm (13.2 inches)
Rear BrakesSingle disc. ABS
Rear Brake Diameter296 mm (11.7 inches)
WheelsCast aluminium

Comments

It appears you're interested in specifications for the Honda VT1300CS. This Custom / cruiser model is powered by a 52° V-twin V2, four-stroke engine with 1312.00 ccm (80.06 cubic inches) of actual displacement before 9.2:1 compression. Fueling is metered via Injection. PGM-FI with automatic enricher circuit allowing this machine to produce its 56.99 HP (41.6 kW) horsepower and 107.00 Nm (10.9 kgf-m or 78.9 ft.lbs) torque. According to our records engine heat of the Honda VT1300CS is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Shaft drive (cardan) maintainence. Our best information shows that the front tire size is 90/90-21 and the rear is 200/50-18 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Twin-piston caliper front brakes and Single disc. ABS rear brakes. The Honda VT1300CS was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Sold in Australia.
