2013 Husqvarna CR125 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2013 Husqvarna CR125.

Basic Specs

Year2013
MakeHusqvarna
ModelHusqvarna CR125
Cost

Engine

Displacement124.82 ccm (7.62 cubic inches)
TypeReed valve in crankcase with power valve
DetailsSingle cylinder, two-stroke
Max RPM
Compression8.8:1
Bore/Stroke54.0 x 54.5 mm (2.1 x 2.1 inches)
Valves/Cylinder
FuelingCarburettor. Mikuni TMX38
Ignition
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchMulti plate, cable operation
Driveline6 speed constant mesh

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity7.00 litres (1.85 gallons)
Emissions

Chassis

Frame TypeChromoly single tube frame cradle utilizes rounded-rectangle elliptical tubing.
Rake
Trail
Front Suspension48mm Kayaba AOS
Front Travel
Rear SuspensionSachs Multi Adjustable Shock with Soft Damp Linkage
Rear Travel
Seat
Seat Height985 mm (38.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,215 mm (87.2 inches)
Total Width820 mm (32.3 inches)
Ground Clearance325 mm (12.8 inches)
Wheelbase1,460 mm (57.5 inches)
Dry Weight92.0 kg (202.8 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre90/90-21
Rear Tire/Tyre
Front BrakesSingle disc. Wave disc.
Front Brake Diameter260 mm (10.2 inches)
Rear BrakesSingle disc. Wave disc.
Rear Brake Diameter240 mm (9.4 inches)
Wheels

Comments

It appears you're interested in specifications for the Husqvarna CR125. This Cross / motocross model is powered by a Reed valve in crankcase with power valve Single cylinder, two-stroke engine with 124.82 ccm (7.62 cubic inches) of actual displacement before 8.8:1 compression. Fueling is metered via Carburettor. Mikuni TMX38 allowing this machine to produce its horsepower and torque. According to our records engine heat of the Husqvarna CR125 is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 90/90-21 and the rear is . The entire package is supported by the frame, Chromoly single tube frame cradle utilizes rounded-rectangle elliptical tubing.. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Wave disc. front brakes and Single disc. Wave disc. rear brakes. The Husqvarna CR125 was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

The model comes with a 144cc top-end kit complete with cylinder and piston for adding 19cc.
