2013 Kawasaki Ninja ZX -14R Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2013 Kawasaki Ninja ZX -14R.

Basic Specs

Year2013
MakeKawasaki
ModelKawasaki Ninja ZX -14R
TypeSport
CostUS$ 14999. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1441.00 ccm (87.93 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression12.3:1
Bore/Stroke84.0 x 65.0 mm (3.3 x 2.6 inches)
Valves/Cylinder
FuelingInjection. DFI with four 44mm Mikuni throttle bodies
IgnitionTCBI with Digital Advance
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
DrivelineX-Ring Chain

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity21.95 litres (5.80 gallons)
Emissions

Chassis

Frame TypeAluminum perimeter
Rake23.0°
Trail94 mm (3.7 inches)
Front Suspension43mm inverted cartridge fork with adjustable preload, 18-way compression and 15-way rebound damping adjustment / 4.6 in.
Front Travel
Rear SuspensionBottom-link Uni-Trak and gas-charged shock with adjustable preload, stepless rebound and compression damping adjustments, adjustable ride height / 4.9 in.
Rear Travel
Seat
Seat Height800 mm (31.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,171 mm (46.1 inches)
Total Length2,169 mm (85.4 inches)
Total Width770 mm (30.3 inches)
Ground Clearance124 mm (4.9 inches)
Wheelbase1,481 mm (58.3 inches)
Dry Weight
Wet Weight265.0 kg (584.3 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre190/50-ZR17
Front BrakesDouble disc. Petal discs with dual radial-mounted four-piston calipers and optional ABS
Front Brake Diameter310 mm (12.2 inches)
Rear BrakesSingle disc. Petal disc with twin-piston caliper and optional ABS
Rear Brake Diameter250 mm (9.8 inches)
Wheels

Comments

It appears you're interested in specifications for the Kawasaki Ninja ZX -14R. This Sport model is powered by a In-line four, four-stroke engine with 1441.00 ccm (87.93 cubic inches) of actual displacement before 12.3:1 compression. Fueling is metered via Injection. DFI with four 44mm Mikuni throttle bodies allowing this machine to produce its horsepower and torque. According to our records engine heat of the Kawasaki Ninja ZX -14R is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 190/50-ZR17 . The entire package is supported by the frame, Aluminum perimeter. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. Petal discs with dual radial-mounted four-piston calipers and optional ABS front brakes and Single disc. Petal disc with twin-piston caliper and optional ABS rear brakes. The Kawasaki Ninja ZX -14R was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
