2013 Kawasaki Z 1000 ABS Special Edition Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2013 Kawasaki Z 1000 ABS Special Edition.

Basic Specs

Year2013
MakeKawasaki
ModelKawasaki Z 1000 ABS Special Edition
Cost

Engine

Displacement1043.00 ccm (63.64 cubic inches)
Type
DetailsIn-line four, four-stroke
Max RPM
Compression11.8:1
Bore/Stroke77.0 x 56.0 mm (3.0 x 2.2 inches)
Valves/Cylinder4
FuelingInjection. DFI with four 38mm Keihin throttle bodies, oval sub-throttles
IgnitionTCBI with Digital Advance
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity15.14 litres (4.00 gallons)
Emissions

Chassis

Frame TypeAluminium twin-tube
Rake24.5°
Trail103 mm (4.1 inches)
Front Suspension41 mm inverted cartridge fork with stepless compression and rebound damping, adjustable spring preload.
Front Travel120 mm (4.7 inches)
Rear SuspensionHorizontal monoshock with stepless rebound damping, adjustable spring preload.
Rear Travel135 mm (5.3 inches)
Seat
Seat Height815 mm (32.1 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,085 mm (42.7 inches)
Total Length2,096 mm (82.5 inches)
Total Width805 mm (31.7 inches)
Ground Clearance140 mm (5.5 inches)
Wheelbase1,440 mm (56.7 inches)
Dry Weight
Wet Weight222.0 kg (489.4 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre190/50-ZR17
Front BrakesDouble disc. ABS. Petal-type rotors with radial-mount four-piston calipers.
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. ABS. Petal-type rotor with single-piston caliper.
Rear Brake Diameter250 mm (9.8 inches)
Wheels

Comments

It appears you're interested in specifications for the Kawasaki Z 1000 ABS Special Edition. This Naked bike model is powered by a In-line four, four-stroke engine with 1043.00 ccm (63.64 cubic inches) of actual displacement before 11.8:1 compression. Fueling is metered via Injection. DFI with four 38mm Keihin throttle bodies, oval sub-throttles allowing this machine to produce its horsepower and torque. According to our records engine heat of the Kawasaki Z 1000 ABS Special Edition is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 190/50-ZR17 . The entire package is supported by the frame, Aluminium twin-tube. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Petal-type rotors with radial-mount four-piston calipers. front brakes and Single disc. ABS. Petal-type rotor with single-piston caliper. rear brakes. The Kawasaki Z 1000 ABS Special Edition was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
