2013 Kymco MXU 500 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2013 Kymco MXU 500.

Basic Specs

Year2013
MakeKymco
ModelKymco MXU 500
TypeATV
CostUS$ 5699. Prices depend on country, taxes, accessories, etc.

Engine

Displacement498.50 ccm (30.42 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.5:1
Bore/Stroke92.0 x 75.0 mm (3.6 x 3.0 inches)
Valves/Cylinder
FuelingCarburettor
IgnitionCDI
Exhaust
LubricationWet sump
CoolingLiquid

Drivetrain

GearboxAutomatic
Final DriveBelt
Clutch
DrivelineAutomatic CVT w/forward, neutral, reverse and park. 2WD/4WD.

Performance

Horespower18.00 HP (13.1 kW)
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity17.00 litres (4.49 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionDual A-arm
Front Travel
Rear SuspensionIndependent dual A-arm
Rear Travel
Seat
Seat Height848 mm (33.4 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,230 mm (87.8 inches)
Total Width1,223 mm (48.1 inches)
Ground Clearance
Wheelbase1,293 mm (50.9 inches)
Dry Weight306.0 kg (674.6 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre25/8-12
Rear Tire/Tyre25/10-12
Front BrakesSingle disc
Front Brake Diameter190 mm (7.5 inches)
Rear BrakesSingle disc
Rear Brake Diameter220 mm (8.7 inches)
Wheels

Comments

It appears you're interested in specifications for the Kymco MXU 500. This ATV model is powered by a Single cylinder, four-stroke engine with 498.50 ccm (30.42 cubic inches) of actual displacement before 10.5:1 compression. Fueling is metered via Carburettor allowing this machine to produce its 18.00 HP (13.1 kW) horsepower and torque. According to our records engine heat of the Kymco MXU 500 is moderated by Liquid. You'll need to get familiar with the Automatic transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 25/8-12 and the rear is 25/10-12 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The Kymco MXU 500 was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

On Demand 2WD/4WD. C.A.R.B. Certified with USFS-Approved Spark Arrestor. Made in Taiwan.
