These are the known mechanical and performance specifications for your 2013 Piaggio Fly 150.

Basic Specs

Year2013
MakePiaggio
ModelPiaggio Fly 150
CostUS$ 2899. Prices depend on country, taxes, accessories, etc.

Engine

Displacement150.00 ccm (9.15 cubic inches)
TypeLEADER 4 engine
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke
Valves/Cylinder2
FuelingCarburettor
IgnitionCDI
Exhaust
LubricationWet sump
CoolingAir

Drivetrain

GearboxAutomatic
Final DriveBelt
Clutch
DrivelineCVT. Automatic twist and go.

Performance

Horespower11.40 HP (8.3 kW)
Torque11.50 Nm (1.2 kgf-m or 8.5 ft.lbs)
Top Speed98.2 km/h (61.0 mph)

Fuel Economy & Polution

Fuel Consumption3.22 litres/100 km (31.1 km/l or 73.05 mpg)
Fuel Capacity7.10 litres (1.88 gallons)
Emissions74.7 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame Type
Rake
Trail
Front SuspensionTelescopic hydraulic forks, 32 mm
Front Travel
Rear SuspensionHydraulic single shock absorber
Rear Travel
Seat
Seat Height785 mm (30.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length1,870 mm (73.6 inches)
Total Width734 mm (28.9 inches)
Ground Clearance
Wheelbase1,331 mm (52.4 inches)
Dry Weight
Wet Weight112.0 kg (246.9 pounds)

Wheels & Brakes

Front Tire/Tyre120/70-12
Rear Tire/Tyre120/70-12
Front BrakesSingle disc
Front Brake Diameter200 mm (7.9 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter140 mm (5.5 inches)
Wheels

Comments

It appears you're interested in specifications for the Piaggio Fly 150. This Scooter model is powered by a LEADER 4 engine Single cylinder, four-stroke engine with 150.00 ccm (9.15 cubic inches) of actual displacement before compression. Fueling is metered via Carburettor allowing this machine to produce its 11.40 HP (8.3 kW) horsepower and 11.50 Nm (1.2 kgf-m or 8.5 ft.lbs) torque. According to our records engine heat of the Piaggio Fly 150 is moderated by Air. You'll need to get familiar with the Automatic transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 120/70-12 and the rear is 120/70-12 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Expanding brake (drum brake) rear brakes. The Piaggio Fly 150 was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
