2013 Pitster Pro X2 Mini GP Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2013 Pitster Pro X2 Mini GP.

Basic Specs

Year2013
MakePitster Pro
ModelPitster Pro X2 Mini GP
CostUS$ 1999. Prices depend on country, taxes, accessories, etc.

Engine

Displacement125.00 ccm (7.63 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression10.1:1
Bore/Stroke54.0 x 54.0 mm (2.1 x 2.1 inches)
Valves/Cylinder
FuelingCarburettor. Mikuni 26mm
IgnitionCDI
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox4-speed
Final DriveChain
ClutchManual
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity1.60 litres (0.42 gallons)
Emissions

Chassis

Frame TypeChromo frame and subframe
Rake
Trail
Front SuspensionInverted, 4 inches of trave
Front Travel
Rear SuspensionOil, Coil Shock 2.75 inches of travel
Rear Travel
Seat
Seat Height667 mm (26.3 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length1,600 mm (63.0 inches)
Total Width495 mm (19.5 inches)
Ground Clearance114 mm (4.5 inches)
Wheelbase1,073 mm (42.3 inches)
Dry Weight
Wet Weight83.9 kg (185.0 pounds)

Wheels & Brakes

Front Tire/Tyre100/80-12
Rear Tire/Tyre120/80-12
Front BrakesSingle disc. Vented Hydraulic Disc
Front Brake Diameter
Rear BrakesSingle disc. Vented Hydraulic Disc
Rear Brake Diameter
WheelsBlack Alloy Mag

Comments

It appears you're interested in specifications for the Pitster Pro X2 Mini GP. This Minibike, sport model is powered by a Single cylinder, four-stroke engine with 125.00 ccm (7.63 cubic inches) of actual displacement before 10.1:1 compression. Fueling is metered via Carburettor. Mikuni 26mm allowing this machine to produce its horsepower and torque. According to our records engine heat of the Pitster Pro X2 Mini GP is moderated by Air. You'll need to get familiar with the 4-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 100/80-12 and the rear is 120/80-12 . The entire package is supported by the frame, Chromo frame and subframe. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Vented Hydraulic Disc front brakes and Single disc. Vented Hydraulic Disc rear brakes. The Pitster Pro X2 Mini GP was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
