2013 Pitster Pro X5 155 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2013 Pitster Pro X5 155.

Basic Specs

Year2013
MakePitster Pro
ModelPitster Pro X5 155
CostUS$ 1899. Prices depend on country, taxes, accessories, etc.

Engine

Displacement140.00 ccm (8.54 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression9.2:1
Bore/Stroke56.0 x 57.0 mm (2.2 x 2.2 inches)
Valves/Cylinder
Fueling
IgnitionOuter Rotor w/ CDI
ExhaustFMF and Pro Circuit
Lubrication
CoolingOil & air

Drivetrain

Gearbox4-speed
Final DriveChain
ClutchFive plate wet clutch
Driveline

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity4.92 litres (1.30 gallons)
Emissions

Chassis

Frame TypeChromoly frame with engine cradle. Subframe: Chromoly Removable.
Rake
Trail
Front Suspension35mm inverted forks
Front Travel
Rear SuspensionMono Shock with preload adjustmen
Rear Travel
Seat
Seat Height787 mm (31.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance254 mm (10.0 inches)
Wheelbase1,181 mm (46.5 inches)
Dry Weight64.9 kg (143.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre2.50-14
Rear Tire/Tyre80/100-12
Front BrakesSingle disc. Hydraulic.
Front Brake Diameter220 mm (8.7 inches)
Rear BrakesSingle disc. Hydraulic.
Rear Brake Diameter190 mm (7.5 inches)
Wheels

Comments

It appears you're interested in specifications for the Pitster Pro X5 155. This Minibike, cross model is powered by a Single cylinder, four-stroke engine with 140.00 ccm (8.54 cubic inches) of actual displacement before 9.2:1 compression. Fueling is metered via allowing this machine to produce its horsepower and torque. According to our records engine heat of the Pitster Pro X5 155 is moderated by Oil & air. You'll need to get familiar with the 4-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 2.50-14 and the rear is 80/100-12 . The entire package is supported by the frame, Chromoly frame with engine cradle. Subframe: Chromoly Removable.. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc. Hydraulic. front brakes and Single disc. Hydraulic. rear brakes. The Pitster Pro X5 155 was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
