2013 Vespa S 150 ie. Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2013 Vespa S 150 ie..

Basic Specs

Year2013
MakeVespa
ModelVespa S 150 ie.
CostUS$ 4499. Prices depend on country, taxes, accessories, etc.

Engine

Displacement150.00 ccm (9.15 cubic inches)
TypeLeader engine
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke62.8 x 48.6 mm (2.5 x 1.9 inches)
Valves/Cylinder
FuelingInjection
Ignition
Exhaust
LubricationWet sump, chain-driven lobe pump
CoolingAir

Drivetrain

GearboxAutomatic
Final DriveBelt
ClutchAutomatic dry centrifugal clutch with vibration dampers
DrivelineCVT transformer with torque slave

Performance

Horespower11.66 HP (8.5 kW)
Torque11.50 Nm (1.2 kgf-m or 8.5 ft.lbs)
Top Speed95.0 km/h (59.0 mph)

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity8.71 litres (2.30 gallons)
Emissions

Chassis

Frame TypeLoad-bearing steel chassis
Rake
Trail
Front SuspensionSingle sided trailing link with hydraulic shock absorber
Front Travel
Rear SuspensionHydraulic shock absorber
Rear Travel
Seat
Seat Height785 mm (30.9 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length1,768 mm (69.6 inches)
Total Width739 mm (29.1 inches)
Ground Clearance
Wheelbase1,278 mm (50.3 inches)
Dry Weight110.0 kg (242.5 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre110/70-11
Rear Tire/Tyre120/70-10
Front BrakesSingle disc
Front Brake Diameter200 mm (7.9 inches)
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter110 mm (4.3 inches)
Wheels

Comments

It appears you're interested in specifications for the Vespa S 150 ie.. This Scooter model is powered by a Leader engine Single cylinder, four-stroke engine with 150.00 ccm (9.15 cubic inches) of actual displacement before compression. Fueling is metered via Injection allowing this machine to produce its 11.66 HP (8.5 kW) horsepower and 11.50 Nm (1.2 kgf-m or 8.5 ft.lbs) torque. According to our records engine heat of the Vespa S 150 ie. is moderated by Air. You'll need to get familiar with the Automatic transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 110/70-11 and the rear is 120/70-10 . The entire package is supported by the frame, Load-bearing steel chassis. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Expanding brake (drum brake) rear brakes. The Vespa S 150 ie. was launched in 2013, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
