2014 ATK GV650 Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2014 ATK GV650.

Basic Specs

Year2014
MakeATK
ModelATK GV650
Cost

Engine

Displacement647.00 ccm (39.48 cubic inches)
Type90 degree V-twin
DetailsV2, four-stroke
Max RPM
Compression11.6:1
Bore/Stroke81.5 x 62.0 mm (3.2 x 2.4 inches)
Valves/Cylinder4
FuelingInjection. EFI
Ignition
Exhaust
Lubrication  Wet sump
CoolingLiquid

Drivetrain

Gearbox5-speed
Final DriveBelt
Clutch  Wet, Multiplate
Driveline

Performance

Horespower79.00 HP (57.7 kW)
Torque66.99 Nm (6.8 kgf-m or 49.4 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity15.90 litres (4.20 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front Suspension Upside down Telescopic (Compression, Rebound damping adjustable)
Front Travel
Rear SuspensionSwing arm with Hydraulic Double shock absorber (Preload adjustable)
Rear Travel
Seat2-person seat
Seat Height706 mm (27.8 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,431 mm (95.7 inches)
Total Width840 mm (33.1 inches)
Ground Clearance160 mm (6.3 inches)
Wheelbase1,699 mm (66.9 inches)
Dry Weight217.7 kg (480.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-ZR18
Rear Tire/Tyre180/55-ZR17
Front BrakesDouble disc. 2 pistons calipers, floating rotor
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc. 2 pistons caliper, floating rotor
Rear Brake Diameter270 mm (10.6 inches)
WheelsThree spoke wheels, black.

Comments

It appears you're interested in specifications for the ATK GV650. This Custom / cruiser model is powered by a 90 degree V-twin V2, four-stroke engine with 647.00 ccm (39.48 cubic inches) of actual displacement before 11.6:1 compression. Fueling is metered via Injection. EFI allowing this machine to produce its 79.00 HP (57.7 kW) horsepower and 66.99 Nm (6.8 kgf-m or 49.4 ft.lbs) torque. According to our records engine heat of the ATK GV650 is moderated by Liquid. You'll need to get familiar with the 5-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 120/70-ZR18 and the rear is 180/55-ZR17 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. 2 pistons calipers, floating rotor front brakes and Single disc. 2 pistons caliper, floating rotor rear brakes. The ATK GV650 was launched in 2014, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
