2014 Bimota Tesi 3D Naked Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2014 Bimota Tesi 3D Naked.

Basic Specs

Year2014
MakeBimota
ModelBimota Tesi 3D Naked
TypeSport
Cost

Engine

Displacement1079.00 ccm (65.84 cubic inches)
TypeDucati 90 degree L-Twin
DetailsV2, four-stroke
Max RPM9000
Compression10.5:1
Bore/Stroke98.0 x 71.5 mm (3.9 x 2.8 inches)
Valves/Cylinder2
FuelingInjection. Walbro
Ignition
Exhaust
Lubrication
CoolingOil & air

Drivetrain

Gearbox6-speed
Final DriveChain
ClutchDry Clutch, multi-disc
Driveline

Performance

Horespower98.00 HP (71.5 kW)
Torque105.00 Nm (10.7 kgf-m or 77.4 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity16.00 litres (4.23 gallons)
Emissions

Chassis

Frame TypeMade of two omega shaped lightweight alloy plates
Rake20.5°
Trail
Front SuspensionSwing arm. Monoshock, Pull-Rod Extreme Tech, fully adjustable (Preload - External Hydraulic device, Compression, Rebound,
Front Travel115 mm (4.5 inches)
Rear SuspensionSwing arm. Extreme Tech Mono Shock fully adjustable,
Rear Travel120 mm (4.7 inches)
Seat
Seat Height800 mm (31.5 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height
Total Length2,010 mm (79.1 inches)
Total Width720 mm (28.3 inches)
Ground Clearance
Wheelbase1,390 mm (54.7 inches)
Dry Weight166.0 kg (366.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-17
Rear Tire/Tyre180/55-17
Front BrakesDouble disc. 4-piston
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. 2-piston
Rear Brake Diameter220 mm (8.7 inches)
WheelsForged Aluminium Alloy

Comments

It appears you're interested in specifications for the Bimota Tesi 3D Naked. This Sport model is powered by a Ducati 90 degree L-Twin V2, four-stroke engine with 1079.00 ccm (65.84 cubic inches) of actual displacement before 10.5:1 compression. Fueling is metered via Injection. Walbro allowing this machine to produce its 98.00 HP (71.5 kW) horsepower and 105.00 Nm (10.7 kgf-m or 77.4 ft.lbs) torque. According to our records engine heat of the Bimota Tesi 3D Naked is moderated by Oil & air. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-17 and the rear is 180/55-17 . The entire package is supported by the frame, Made of two omega shaped lightweight alloy plates. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. 4-piston front brakes and Single disc. 2-piston rear brakes. The Bimota Tesi 3D Naked was launched in 2014, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Italian brand.
