2014 Ecosse Iconoclast Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2014 Ecosse Iconoclast.

Basic Specs

Year2014
MakeEcosse
ModelEcosse Iconoclast
Cost

Engine

Displacement1966.00 ccm (119.97 cubic inches)
TypeMachined from solid billet aluminum
DetailsV2, four-stroke
Max RPM
Compression
Bore/Stroke108.0 x 108.0 mm (4.3 x 4.3 inches)
Valves/Cylinder
Fueling
Ignition
ExhaustSpecial custom racing exhaust for Iconoclast Series; machined from solid with ECOSSE logo machined on mufflers. Exhaust duplexer located for maximum torque.
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveChain
Clutch
Driveline

Performance

Horespower135.00 HP (98.5 kW)
Torque189.84 Nm (19.4 kgf-m or 140.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity
Emissions

Chassis

Frame Type4130 Chrome-moly TIG welded by hand. FEA tested. Oil circulates through 3” backbone and all four 1¿ down tubes for additional cooling. Trellis-style double-sided swingarm and subframe.
Rake
Trail
Front SuspensionCustom Öhlins, fully adjustable forks
Front Travel
Rear SuspensionÖhlins custom shocks
Rear Travel
Seat
Seat Height
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance
Wheelbase1,537 mm (60.5 inches)
Dry Weight208.7 kg (460.0 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre120/70-ZR17
Rear Tire/Tyre190/70-ZR17
Front BrakesDouble disc. ISR radial brake system. Dual 6-piston front brakes with 12 individual brake pads for maximum grip. Machined from billet.
Front Brake Diameter320 mm (12.6 inches)
Rear BrakesSingle disc. 2-piston calipers
Rear Brake Diameter260 mm (10.2 inches)
WheelsBlack forged aluminum 17” wheels

Comments

It appears you're interested in specifications for the Ecosse Iconoclast. This Naked bike model is powered by a Machined from solid billet aluminum V2, four-stroke engine with 1966.00 ccm (119.97 cubic inches) of actual displacement before compression. Fueling is metered via allowing this machine to produce its 135.00 HP (98.5 kW) horsepower and 189.84 Nm (19.4 kgf-m or 140.0 ft.lbs) torque. According to our records engine heat of the Ecosse Iconoclast is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 120/70-ZR17 and the rear is 190/70-ZR17 . The entire package is supported by the frame, 4130 Chrome-moly TIG welded by hand. FEA tested. Oil circulates through 3” backbone and all four 1¿ down tubes for additional cooling. Trellis-style double-sided swingarm and subframe.. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ISR radial brake system. Dual 6-piston front brakes with 12 individual brake pads for maximum grip. Machined from billet. front brakes and Single disc. 2-piston calipers rear brakes. The Ecosse Iconoclast was launched in 2014, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Limited edition of only 11 bikes.
