2014 Honda TRX90X Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2014 Honda TRX90X.

Basic Specs

Year2014
MakeHonda
ModelHonda TRX90X
TypeATV
CostUS$ 2999. Prices depend on country, taxes, accessories, etc.

Engine

Displacement86.00 ccm (5.25 cubic inches)
Type
DetailsSingle cylinder, four-stroke
Max RPM
Compression
Bore/Stroke47.0 x 49.5 mm (1.9 x 1.9 inches)
Valves/Cylinder
FuelingCarburettor. 15mm piston-valve carburetor
IgnitionCDI
Exhaust
Lubrication
CoolingAir

Drivetrain

Gearbox4-speed
Final DriveChain
ClutchAutomatic
DrivelineO-ring-sealed chain

Performance

Horespower
Torque
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity6.43 litres (1.70 gallons)
Emissions

Chassis

Frame Type
Rake
Trail
Front SuspensionIndependent suspension
Front Travel66 mm (2.6 inches)
Rear SuspensionSwingarm with single shock
Rear Travel66 mm (2.6 inches)
Seat
Seat Height660 mm (26.0 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height927 mm (36.5 inches)
Total Length1,488 mm (58.6 inches)
Total Width894 mm (35.2 inches)
Ground Clearance99 mm (3.9 inches)
Wheelbase983 mm (38.7 inches)
Dry Weight
Wet Weight118.8 kg (262.0 pounds)

Wheels & Brakes

Front Tire/Tyre20/7-8
Rear Tire/Tyre19/8-8
Front BrakesDouble disc
Front Brake Diameter
Rear BrakesExpanding brake (drum brake)
Rear Brake Diameter
Wheels

Comments

It appears you're interested in specifications for the Honda TRX90X. This ATV model is powered by a Single cylinder, four-stroke engine with 86.00 ccm (5.25 cubic inches) of actual displacement before compression. Fueling is metered via Carburettor. 15mm piston-valve carburetor allowing this machine to produce its horsepower and torque. According to our records engine heat of the Honda TRX90X is moderated by Air. You'll need to get familiar with the 4-speed transmission and pay attention to final drive Chain maintainence. Our best information shows that the front tire size is 20/7-8 and the rear is 19/8-8 . The entire package is supported by the frame, . We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc front brakes and Expanding brake (drum brake) rear brakes. The Honda TRX90X was launched in 2014, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Model ID: TRX90X
