2014 Kawasaki Vulcan 1700 Voyager Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2014 Kawasaki Vulcan 1700 Voyager.

Basic Specs

Year2014
MakeKawasaki
ModelKawasaki Vulcan 1700 Voyager
CostUS$ 18249. Prices depend on country, taxes, accessories, etc.

Engine

Displacement1700.00 ccm (103.73 cubic inches)
Type52° V-twin
DetailsV2, four-stroke
Max RPM
Compression9.5:1
Bore/Stroke102.0 x 104.0 mm (4.0 x 4.1 inches)
Valves/Cylinder4
FuelingInjection. DFI with dual 42mm throttle bodies
IgnitionTCBI with Digital Advance
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox6-speed
Final DriveBelt
Clutch
Driveline

Performance

Horespower
Torque146.45 Nm (14.9 kgf-m or 108.0 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption
Fuel Capacity20.06 litres (5.30 gallons)
Emissions

Chassis

Frame TypeSteel, double-cradle with box-section single-tube backbone
Rake30.0°
Trail178 mm (7.0 inches)
Front Suspension45mm hydraulic fork / 5.5 in.
Front Travel
Rear SuspensionSwingarm with twin air-assisted shocks, with 4-way rebound damping / 3.1 in.
Rear Travel
Seat
Seat Height
Alt. Seat Height
Total Height
Total Length
Total Width
Ground Clearance135 mm (5.3 inches)
Wheelbase1,666 mm (65.6 inches)
Dry Weight
Wet Weight401.9 kg (886.0 pounds)

Wheels & Brakes

Front Tire/Tyre130/90-16
Rear Tire/Tyre170/70-16
Front BrakesDouble disc. ABS. Four-piston calipers.
Front Brake Diameter300 mm (11.8 inches)
Rear BrakesSingle disc
Rear Brake Diameter300 mm (11.8 inches)
Wheels

Comments

It appears you're interested in specifications for the Kawasaki Vulcan 1700 Voyager. This Touring model is powered by a 52° V-twin V2, four-stroke engine with 1700.00 ccm (103.73 cubic inches) of actual displacement before 9.5:1 compression. Fueling is metered via Injection. DFI with dual 42mm throttle bodies allowing this machine to produce its horsepower and 146.45 Nm (14.9 kgf-m or 108.0 ft.lbs) torque. According to our records engine heat of the Kawasaki Vulcan 1700 Voyager is moderated by Liquid. You'll need to get familiar with the 6-speed transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 130/90-16 and the rear is 170/70-16 . The entire package is supported by the frame, Steel, double-cradle with box-section single-tube backbone. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Double disc. ABS. Four-piston calipers. front brakes and Single disc rear brakes. The Kawasaki Vulcan 1700 Voyager was launched in 2014, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.
