2014 Yamaha TMAX Hypermodified Specs

motorcycle specs

These are the known mechanical and performance specifications for your 2014 Yamaha TMAX Hypermodified.

Basic Specs

Year2014
MakeYamaha
ModelYamaha TMAX Hypermodified
Cost

Engine

Displacement499.00 ccm (30.45 cubic inches)
TypeForward inclined parallel cylinders
DetailsTwin, four-stroke
Max RPM
Compression11.0:1
Bore/Stroke66.0 x 73.0 mm (2.6 x 2.9 inches)
Valves/Cylinder4
FuelingInjection. Electronic fuel injection
IgnitionDigital TCI: Transistor Controlled Ignition
Exhaust
Lubrication
CoolingLiquid

Drivetrain

Gearbox
Final DriveBelt
ClutchWet, multiple-disc automatic centrifugal
DrivelineV-belt

Performance

Horespower45.86 HP (33.5 kW)
Torque52.30 Nm (5.3 kgf-m or 38.6 ft.lbs)
Top Speed

Fuel Economy & Polution

Fuel Consumption5.00 litres/100 km (20.0 km/l or 47.04 mpg)
Fuel Capacity15.14 litres (4.00 gallons)
Emissions116.0 CO2 g/km. (CO2 - Carbon dioxide emission)

Chassis

Frame TypeDdie-cast aluminium frame
Rake
Trail
Front SuspensionYZ450F fork
Front Travel275 mm (10.8 inches)
Rear SuspensionSwingarm
Rear Travel116 mm (4.6 inches)
Seat
Seat Height900 mm (35.4 inches) If adjustable, lowest setting.
Alt. Seat Height
Total Height1,445 mm (56.9 inches)
Total Length2,195 mm (86.4 inches)
Total Width775 mm (30.5 inches)
Ground Clearance280 mm (11.0 inches)
Wheelbase1,580 mm (62.2 inches)
Dry Weight164.0 kg (361.6 pounds)
Wet Weight

Wheels & Brakes

Front Tire/Tyre110/80-19
Rear Tire/Tyre150/70-17
Front BrakesSingle disc
Front Brake Diameter267 mm (10.5 inches)
Rear BrakesSingle disc
Rear Brake Diameter267 mm (10.5 inches)
Wheels

Comments

It appears you're interested in specifications for the Yamaha TMAX Hypermodified. This Super motard model is powered by a Forward inclined parallel cylinders Twin, four-stroke engine with 499.00 ccm (30.45 cubic inches) of actual displacement before 11.0:1 compression. Fueling is metered via Injection. Electronic fuel injection allowing this machine to produce its 45.86 HP (33.5 kW) horsepower and 52.30 Nm (5.3 kgf-m or 38.6 ft.lbs) torque. According to our records engine heat of the Yamaha TMAX Hypermodified is moderated by Liquid. You'll need to get familiar with the transmission and pay attention to final drive Belt maintainence. Our best information shows that the front tire size is 110/80-19 and the rear is 150/70-17 . The entire package is supported by the frame, Ddie-cast aluminium frame. We know you like to go fast or cruise all day, but when you need to stop, you'll be dependant on Single disc front brakes and Single disc rear brakes. The Yamaha TMAX Hypermodified was launched in 2014, and we're happy to know (or assume) you've got one in your garage. To help you keep your ride in tip-top shape, consider purchasing an owner or service manual.

Also called Yamaha TCROSS Hyper Modified. Windshield.
